纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (05-001) - COUNTERWEIGHT INSTAL, (GAIN) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
583 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW60C00017F2 | [1] | COUNTERWEIGHT | KOBINSTAL, (GAIN) |
| 1. | PW60C00016P1 | [1] | WEIGHT | KOBCOUNTER |
| 2. | HS18C20125G1 | [2] | SCREW | KOBCAP |
| 3. | HY26Y21050G4 | [2] | WASHER | KOB |
| 4. | LE60C01028P1 | [2] | PLATE | KOB |
| 6. | YN20T01221P1 | [2] | DANGER DECAL | KOBDecal, Danger, Do not use counterweight lifting eyes to lift whole machine.… |
