神钢零件查询(K912A) - EXCAVATOR BTW LC-2003 - LC-2016 (1/85-12/03) (08-002) - INSTAL NAME-PLATE (FOR EXPORT) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
453 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J8057F1 | [1] | INSTAL, NAME PLATE(FOR EXPORT) | |
| 1. | 2432T3016 | [1] | LABEL | KOB |
| 2. | 2432N1249D13 | [1] | LABEL | KOB |
| 3. | 2432X313 | [1] | LABEL | LABEL |
| 4. | 2432N1279D7 | [1] | LABEL | KOB |
| 5. | 2432X278 | [1] | LABEL | LABEL |
| 6. | 2432X314 | [1] | LABEL | LABEL |
| 7. | 2432N1249D14 | [1] | LABEL | KOB |
| 8. | 2432N1249D12 | [1] | LABEL | LABEL |
| 9. | 2432N1249D11 | [1] | LABEL | LABEL |
| 10. | 2432T3017 | [1] | LABEL | KOB |
| 11. | 2432J681 | [2] | NAME-PLATE | NAME-PLATE |
| 12. | 2432N1279D8 | [1] | LABEL | KOB |
| 13. | 2432T1530 | [1] | IDENTITY PLATE | KOBLABEL |
| 14. | 4020Z64 | [2] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 16. | 2427Z329 | [2] | SHEET | KOBAnti-Slip (300x150mm) |
| 17. | 2427Z329D2 | [3] | SHEET | KOBAnti-Slip (400x150mm) |
| 18. | 2432N568 | [1] | INSTALLER JIG | KOBCAUTION Superseded by part number: 2432N1751 |
| 19. | 2432J1717 | [1] | LABEL | LABEL |
| 20. | 2432T1753 | [1] | LABEL | KOBDecal, Kobelco Operation Superseded by part number: YN20T01407P1 |
| 22. | 2432T1754 | [1] | LABEL | LABEL |
| 24. | 2432T1202 | [1] | PLATE | KOB |
| 26. | 2432T892 | [1] | LABEL | KOB |
| 27. | 2432T1142 | [1] | LABEL | KOB |
