纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (05-012[01]) - CAB ASSY (COOLER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
957 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW02C00069F1 | [1] | CAB | KOBCAB ASSY |
| 1. | PW02C00063P2 | [1] | CAB | |
| 6. | PW02C01205P1 | [1] | GLASS | KOB Superseded by part number: PW02C01205P2 |
| . . | PW02C01336P2 | [1] | LABEL | KOBDecal, Window Tint (736x345.5mm) -- No Shown |
| 7. | PW02C01204P1 | [1] | GLASS | KOB |
| 8. | YT51C01021P1 | [1] | HOOK | KOB |
| 9. | PW02C01110P1 | [2] | BRACKET | KOB |
| 13. | PW02C01220P1 | [2] | SPACER | KOB |
| 15. | PM02C01172D1 | [1] | SEAL,7mm W x 4.8mm H x 3000mm L | KOB Superseded by part number: YR02C01511D4 |
| 16. | PM02C01172D2 | [2] | SEAL,7mm W x 4.8mm H x 2500mm L | KOB Superseded by part number: YR02C01511D2 |
| 19. | PM02C01357P1 | [1] | HARNESS | KOB |
| 23. | YT51C01077D1 | [1] | SPACER | KOB |
| 53. | PM51C00006F1 | [1] | DOOR ASSY. | KOBCAB, SEE FIG 01-042 Superseded by part number: PM51C00006F1%LD |
| 55. | PW02C01293P1 | [1] | GLASS | KOB Superseded by part number: PW02C01293P2 |
| 59. | PM54S00001P1 | [1] | ANTENNA | KOB |
| 63. | YT02C01066P1 | [2] | STOP | KOB |
| 71. | 2420R372D16 | [1] | GROMMET | KOB |
| 80. | ZS68C10025 | [2] | CAPSCREW | KOBSCREW CAP |
| 85. | ZS28C08025 | [2] | SCREW,Hex Socket Head, M8 x 25mm | KOBCAP |
| 92. | ZN18F10008 | [2] | NUT | KOB |
| 96. | ZW26X08000 | [4] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| 101. | ZW16X10000 | [2] | WASHER | KOB |
| 102. | ZW16X08000 | [10] | WASHER | KOB |
| 105. | PM02C01353P1 | [1] | WASHER | KOB |
| 115. | 2420R372D15 | [1] | GROMMET | KOB |
| 117. | PM02C01482D6 | [2] | NUT | KOB |
| 120. | PM02C01499P1 | [1] | HARNESS | KOB |
| 123. | YT51C01081D2 | [1] | SEAL | KOB Superseded by part number: YT51C01081D1 |
| 126. | PM41C00015P1 | [1] | HANDRAIL | KOB |
| 127. | YR02C01571D2 | [2] | SCREW | KOBCAP |
| 128. | ZW16H10000 | [2] | WASHER | KOB |
| 133. | PW11E01034D1 | [1] | HARNESS | KOB |
| 135. | ZS28C08035 | [2] | SCREW,Hex Socket Head, M8 x 35mm | KOBCAP |
| 151. | ZS18C08012 | [6] | SCREW,Hex, M8 x 12mm | KOBCAP |
| 154. | PW02C01353P1 | [1] | PROTECTION STRIP | KOBSTRIP, WEATHER |
