卡特零件查询（730C） 272-1889: ALTERNATOR GP-CHARGING
广数供应链运营团队, 15 02月, 2025，浏览：
487 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 478-4968 | [1] | FRAME-DRIVE END | |
| 2. | 478-4950 | [1] | FAN AS | |
| 3. | 478-4970 | [1] | FRAME-REAR | |
| 4. | 478-4971 | [1] | COVER AS-ALTERNATOR | |
| 5. | 185-2647 | [1] | GROMMET | |
| 6. | 478-4955 | [1] | STATOR AS | |
| 7. | 185-2654 | [1] | PLATE | |
| 8. | 478-4958 | [1] | ROTOR AS | |
| 9. | 478-4959 | [1] | COIL AS | |
| 10. | 185-2648 | [1] | REGULATOR AS-VOLTAGE(24-VOLT) | |
| | | | |
| | | | AVAILABLE REPAIR KIT(S): |
| | 478-4961 | [1] | KIT-COLLAR(ALTERNATOR) | |
| | | | (INCLUDES COLLARS) |
| | 478-4962 | [1] | KIT-BEARING(ALTERNATOR) | |
| | | | (INCLUDES BEARINGS) |
| | 478-4963 | [1] | KIT-HARDWARE(ALTERNATOR) | |
| | | | (INCLUDES BOLTS & PLATE) |
| | 478-4964 | [1] | KIT-TERMINAL(ALTERNATOR) | |
| | | | (INCLUDES HOLDER AS,PLATE,INSULATION,PIN,GROMMET & NUT) |
| | 478-4967 | [1] | KIT-TERMINAL(ALTERNATOR) | |
| | | | (INCLUDES INSULATIONS,WASHERS & NUTS) |
