| . . | 24100X2142F1 | [1] | REMOTE CONTROL ASSY | REMOTE CONTROL ASSY |
| 1. | 2436U944F3 | [2] | PILOT VALVE | KOB |
| 2. | 2436U1746F1 | [1] | VALVE, PILOT | VALVE, PILOT |
| 3. | 2446R151F1 | [1] | ELEMENT | KOBFILTER, LINE Superseded by part number: 2446R183F1 |
| 3-1. | 2446R151S1 | [1] | HEAD | KOB |
| 3-2. | R36P0019 | [1] | HYDRAULIC OIL FILTER | KOB |
| 3-3. | 45Z91D84 | [1] | O-RING | KOBID 56.74 ± 0.25 OD 63.80mm |
| 3-4. | 2446R151S4 | [1] | RING | KOB |
| 3-5. | 2446R151S5 | [1] | CASE | KOB |
| 4. | 2416P10323 | [1] | BLOCK | |
| 5. | 2418P7670 | [1] | TUBE | KOB |
| 6. | R18P0168D9 | [1] | HOSE \u00d825.4x380mm Long | HOSE Ø25.4x380mm Long |
| 7. | 2420R537D120 | [2] | HOSE ASSY.,9.60mm ID x 1200mm L | KOB1200mm Long (47-1/4 in) Superseded by part number: HX21E06120DX |
| 8. | 2420R349D16 | [1] | HOSE | KOBHOSE 160mm Long (6-9/32 in) Superseded by part number: HX21E04330DX |
| 9. | 2420R349D14 | [1] | FLEXIBLE HOSE | KOB140mm Long (5-1/2 in) Superseded by part number: HX21E04100DX |
| 10. | 2420R349D450 | [4] | FLEXIBLE HOSE | KOB4500mm Long (177-5/32 in) |
| 11. | 2420R349D490 | [2] | HOSE ASSY 4900mm Long (192-29/32 in) | HOSE ASSY 4900mm Long (192-29/32 in) |
| 12. | 2420R537D260 | [1] | HOSE,9.60mm ID x 2600mm L | KOB |
| 13. | 2420R349D400 | [1] | FLEXIBLE HOSE | KOB4000mm Long (157-31/64 in) |
| 14. | 2420R349D420 | [2] | HOSE | KOB4200mm Long (165-3/8 in) Superseded by part number: HX21E04420DX |
| 15. | 2420R349D360 | [1] | HOSE,3600.00 mm | KOB Superseded by part number: HX21E04360DX |
| 16. | 2420R349D470 | [2] | HOSE 4700mm Long (185-1/32 in) | HOSE 4700mm Long (185-1/32 in) |
| 17. | 2420R349D120 | [5] | HOSE,6.35mm ID x 1200mm L | KOB |
| 18. | 2420R349D160 | [2] | HOSE,6.35mm ID x 1600mm L | KOB |
| 19. | 2420R349D170 | [2] | FLEXIBLE HOSE | KOB1700mm Long (66-59/64 in) Superseded by part number: HX21E04170DX |
| 20. | 2420R537D230 | [1] | FLEXIBLE HOSE,9.60mm ID x 2300mm L | KOB2300mm Long (90-1/2 in) |
| 22. | ZX15K08040 | [1] | PLASTIC-RUBBER TUBE | KOB |
| 23. | ZX15K08050 | [1] | PLASTIC-RUBBER TUBE | KOB |
| 24. | ZX15K08240 | [1] | TUBE, NYLON | TUBE, NYLON |
| 25. | ZX15K08080 | [2] | TUBE, NYLON | TUBE, NYLON |
| 26. | ZF23F15006 | [4] | CONNECTOR, ELEC | KOBCONNECTOR |
| 27. | ZD12P01100 | [5] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 28. | ZD12P01400 | [6] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 29. | ZD12P02240 | [1] | O-RING | KOBID 22.10 ± 0.24 x OD 28.4mm |
| 30. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 31. | ZF23F22012 | [1] | HYD CONNECTOR | KOB |
| 32. | ZF23H15008 | [1] | HYD CONNECTOR | KOB |
| 33. | ZH42X04000 | [14] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004) |
| 34. | ZF33F15006 | [1] | HYD CONNECTOR | KOBCONNECTOR |
| 35. | ZF23H15006 | [3] | HYD CONNECTOR | KOB |
| 36. | ZH21M08006 | [3] | HYD CONNECTOR | KOB |
| 37. | ZH21M08004 | [4] | HYD CONNECTOR | KOB |
| 38. | ZH22X04000 | [10] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 39. | ZH22X06000 | [4] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) (PF3/8) |
| 39-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 40. | ZH32X06008 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 1/2", O-Ring | KOB90° -- 3/8"PFx1/2"PFx40mm Long (Same as ZD12P02400) |
| 40-2. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 41. | ZH32X06000 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 41-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 42. | ZH32X04000 | [20] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 42-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 43. | ZH31M08004 | [1] | ELBOW | KOB |
| 41. | 2444P1098D1 | [1] | HYD CONNECTOR | KOB3/8" PF x 50mm Long (Incls. O-Ring ZD12P01400) |
| 45. | ZH31M08006 | [3] | ELBOW | KOB |
| 46. | ZH51M08006 | [1] | TEE | KOB |
| 47. | ZH52X04000 | [2] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004) |
| 46. | 2420T3483 | [6] | GROMMET | KOB |
| 49. | ZE72X04000 | [1] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 49-2. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 50. | ZE72X06000 | [3] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| 51. | 2444T3120 | [2] | TEE | KOB |
| 51-2. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 52. | 2418T7100 | [1] | SPACER | SPACER |
| 53. | ZC15X03300 | [4] | CLIP | KOB |
| 54. | 2432Z290 | [20] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 55. | 2420T3804 | [1] | CAPSCREW | CAPSCREW |
| 56. | ZS18C08060 | [2] | SCREW,Hex, M8 x 60mm | KOBM08x1.25x60mm |
| 57. | ZS18C08055 | [1] | CAPSCREW,Hex, M8 x 55mm | KOBSCREW M08x1.25x55mm |
| 58. | ZS18C06045 | [2] | CAP,Hex, M6 x 45mm | KOBScrew -- M06x1.0x45mm |
| 59. | ZN18C06005 | [3] | NUT | KOBM06x1.0mm |
| 60. | ZW16K06000 | [1] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 61. | ZW26X06000 | [11] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 62. | ZW26X06000 | [7] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 63. | 2444T3178 | [2] | CROSS | |
| 64. | ZX15K08140 | [1] | TUBE, NYLON | TUBE, NYLON |
| 65. | ZX15K08100 | [1] | TUBE | KOB |
| 66. | ZX15K08070 | [1] | FLEXIBLE HOSE | KOB |
| 67. | ZH51K08000 | [2] | TEE | KOB |
| 68. | ZS23C06020 | [8] | SCREW,Hex Socket Head, M6 x 20mm | KOBM06x1.0x20mm Superseded by part number: ZS28C06020 |
| 69. | 2436U1800F1 | [1] | VALVE, SOLENOID | VALVE, SOLENOID |
| 70. | 2418T10562 | [1] | PLATE | |
| 71. | 2436U989D3F1 | [1] | VALVE | KOB |
| 72. | 2420R349D6 | [2] | FLEXIBLE HOSE | KOB Superseded by part number: 2420R349D050 |
| 73. | 2420R537D180 | [1] | HOSE,9.60mm ID x 1800mm L | KOB1800mm Long (70-7/8 in) |
| 74. | 2420R537D050 | [1] | HOSE,9.53mm ID x 500mm L | KOB |
| 75. | 2420R537D070 | [1] | HOSE,9.60mm ID x 700mm L | KOB700mm Long (27-1/2 in) |
| 76. | ZS23C06025 | [2] | SCREW,Hex Socket Head, M6 x 25mm | KOBM06x1.0x25mm |
| 77. | 2444P1085D1 | [4] | HYD CONNECTOR | KOB |
| 78. | 2418R312D2 | [1] | PLATE | KOB |
| 79. | ZS18C10040 | [2] | SCREW,Hex, M10 x 40mm | KOBM10x1.50x40mm |
| 80. | ZN18C10006 | [2] | NUT | KOBM10x1.50mm |
| 81. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 82. | 2444Z2256 | [1] | HOSE | HOSE |
| 83. | 2444Z2255 | [4] | CONNECTOR | CONNECTOR |
| 84. | ZC15X05000 | [4] | CLIP | KOB |
| 85. | ZN16C08007 | [2] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 86. | 2432T1818 | [1] | CLAMP | CLAMP |
| 87. | ZS18C08014 | [2] | SCREW,Hex, M8 x 14mm | KOBM08x1.25x14mm |
| 88. | 2436R1117F1 | [1] | VALVE PRESSURE RELIE | KOB |
| 89. | ZS23C08020 | [4] | SCREW,Hex Socket Head, M8 x 20mm | KOBM08x1.25x20mm |
| 90. | ZW26K08000 | [4] | LOCK WASHER | KOBID 08 x OD 13 x Th 2.0mm |
| 92. | 2420R349D23 | [1] | HOSE ASSY | HOSE ASSY |
| 93. | ZX15K08120 | [1] | FLEXIBLE HOSE | KOB |
| 94. | 2444T3175 | [1] | TEE | TEE |
| 95. | 2444T3182 | [1] | TEE | KOB |
| 96. | 2444T3183 | [1] | ELBOW | KOB |
| 97. | 2444T3176 | [1] | TEE | TEE |
| 96. | 2444T3177 | [1] | TEE | |
| 99. | 2432N578 | [1] | PLATE | KOB |
| 100. | 2444T3120 | [1] | TEE | KOB |
| 101. | 2444Z2256D3 | [1] | HOSE | HOSE |
| 102. | 2444Z2704 | [2] | TEE | TEE |
| 103. | 2444T3186 | [1] | TEE | KOB(2) 3/8" PF x 1/4" PF x 50mm Long (Incls. O-Ring ZD12P01400) |
