神钢零件查询(K912A) - EXCAVATOR BTW LC-2003 - LC-2016 (1/85-12/03) (04-001[01]) - HYDR LINES, UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
699 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X2017F2 | [1] | HYDR LINES, UPP | |
| 2. | 2436R387F1 | [1] | VALVE, CHECK | VALVE, CHECK |
| 4. | 2416P7796 | [1] | BRACKET | |
| 8. | 2418P9662 | [1] | TUBE | KOB |
| 9. | 2418P9663 | [1] | TUBE | TUBE |
| 10. | 2418T9729 | [2] | TUBE | KOB |
| 13. | 2418N1862 | [1] | INLET MANIFOLD | KOB |
| 15. | 2418T7002D3 | [1] | FLEXIBLE HOSE | KOB |
| 16. | 2418T7002D2 | [1] | FLEXIBLE HOSE | KOB |
| 17. | 2444Z1697D1 | [1] | HOSE | KOB |
| 18. | 2418T7189D2 | [1] | TUBE | TUBE |
| 19. | ZG15F03800 | [1] | COUPLING | KOB |
| 21. | ZX38S16110 | [2] | WIRE HARNESS | KOB |
| 23. | ZF33F22012 | [1] | ELBOW | KOB |
| 24. | ZG15F05100 | [2] | COUPLING | KOB |
| 25. | ZG15F04500 | [5] | COUPLING | KOB |
| 26. | 2416T11552 | [1] | BRACKET | |
| 27. | 2416T4348 | [2] | CLAMP | CLAMP |
| 28. | 2432T1588 | [6] | CLAMP | KOB |
| 29. | 2420T2948D5 | [5] | U-BOLT | KOBM08x1.25x ID 45 x 80.5mm Long |
| 30. | 2420T2948D4 | [1] | BOLT | KOBU-Bolt -- M08x1.25x ID 51 x 83.5mm Long |
| 31. | R44T0187 | [2] | CONNECTOR | CONNECTOR |
| 32. | 2444R715D16 | [1] | CONNECTOR | CONNECTOR |
| 33. | ZF53B22000 | [1] | TEE | KOB |
| 34. | 2420Z804 | [2] | LOCK NUT | KOB |
| 35. | 2420T2948D6 | [1] | U-BOLT | KOBM08x1.25x ID 64 x 100mm Long |
| 37. | ZC15X08000 | [4] | CLIP | KOBCLIP |
| 38. | ZC15X10500 | [8] | CLIP | KOB |
| 39. | ZD12P02400 | [3] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 40. | ZD12P03400 | [4] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 41. | ZD11G05000 | [3] | O-RING,3.1mm Thk x 49.4mm ID, 70 Duro | KOBO-Ring -- ID 49.40 ± 0.45 x OD 55mm |
| 42. | ZD11P03800 | [1] | O-RING | KOB |
| 43. | ZD12P04400 | [2] | O-RING | KOB |
| 44. | ZE13X16000 | [4] | FLANGE | KOBClamp, Half -- (Incls. Capscrew & Lockwasher) |
| 47. | 2418N2098 | [1] | TUBE | TUBE |
| 48. | ZS18C10030 | [3] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 49. | ZS18C10040 | [3] | SCREW,Hex, M10 x 40mm | KOBM10x1.50x40mm |
| 50. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 51. | ZS18C12045 | [8] | SCREW,Hex, M12 x 45mm | KOBM12x1.75x45mm |
| 52. | ZS18C12060 | [3] | SCREW,Hex, M12 x 60mm | KOBM12x1.75x60mm |
| 53. | ZS18C12070 | [4] | SCREW,Hex, M12 x 70mm | KOBM12x1.75x70mm |
| 54. | ZS18C16040 | [6] | SCREW,Hex, M16 x 40mm | KOBM16x2.0x40mm |
| 55. | ZS23C12035 | [16] | SCREW,Hex Socket Head, M12 x 35mm | KOBM12x1.75x35mm |
| 56. | ZS23C12040 | [8] | SCREW,Hex Socket Head, M12 x 40mm | KOBM12x1.75x40mm |
| 57. | ZN18C08007 | [28] | NUT | KOBM08x1.25mm |
| 56. | ZN18C10008 | [6] | NUT | KOBM10x1.50mm |
| 59. | ZN18C12010 | [7] | NUT | KOBM12x1.75mm |
| 60. | ZW16X08000 | [14] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 61. | 2418T5373C2 | [19] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 62. | ZW16H12000 | [7] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 63. | ZW16H16000 | [6] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 64. | ZW26X10000 | [8] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 65. | ZW26X12000 | [11] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 66. | ZW26X16000 | [6] | LOCK WASHER | KOBID 16 x OD 28 x Th 4.0mm |
| 67. | ZW22K12000 | [24] | LOCK WASHER | KOBID 12.2 x OD 17.8 x Th 2.5mm |
| 68. | 2418N2676 | [1] | TUBE | TUBE |
| 69. | 2418P14554 | [1] | TUBE | TUBE |
| 70. | 2418P14553 | [1] | TUBE | KOB |
| 72. | 2416N3954 | [1] | STAND, VALVE | |
| 73. | 2436U1744F1 | [1] | VALVE, CONTROL | VALVE, CONTROL |
| 74. | 2418P14561 | [1] | PIPE | KOB |
| 75. | 2418P14552 | [1] | SUCTION PIPE | KOB |
| 76. | 2418P14562 | [1] | PIPE | PIPE |
| 77. | 2418N2677 | [1] | TUBE TUBE | TUBE TUBE |
| 78. | ZE72X04000 | [3] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 78-2. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 71. | ZX21M12046 | [1] | FLEXIBLE HOSE | KOB460mm Long (18-7/64 in) Superseded by part number: ZX21M12050 |
