现代零件查询R450LC-7A BOOM MOUNTING(BM 11.5M, #0290-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
333 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
61NA-00011BG
|
[1] |
PIN ASSY
|
|
| 2. |
61N8-01871BG
|
[2] |
PIN ASSY
|
|
| 3. |
61NB-00071
|
[1] |
PIN ASSY
|
|
| 4. |
61N8-01941
|
[2] |
PIN ASSY
|
|
| 5. |
61NB-00032
|
[1] |
PIN WA
|
|
| 6. |
61N8-01611
|
[1] |
PIN ASSY
|
|
| 7. |
61NB-00040BG
|
[1] |
PLATE-LOCK
|
|
| 8. |
61N8-00160
|
[1] |
SPACER-PIN
|
|
| 8. |
61Q8-00140
|
[1] |
SPACER-PIN
|
|
| 9. |
61N8-10810
|
[1] |
PLATE-LOCK
|
|
| 10. |
61N8-00180
|
[2] |
SPACER-PIN
|
|
| 10. |
61Q8-00160
|
[2] |
SPACER-PIN
|
|
| 11. |
61N8-00190
|
[2] |
SPACER-PIN
|
|
| 11. |
61Q8-00170
|
[2] |
SPACER-PIN
|
|
| 12. |
S017-20035D
|
[2] |
BOLT-HEX
|
|
| 13. |
S017-20030D
|
[5] |
BOLT-HEX
|
|
| 14. |
S017-16045D
|
[2] |
BOLT-HEX
|
|
| 15. |
61N8-00320-DA
|
[5] |
WASHER-HARDENED
|
|
| 16. |
S411-200006
|
[2] |
WASHER-SPRING
|
|
| 17. |
S411-160006
|
[2] |
WASHER-SPRING
|
|
| 18. |
61N8-00310
|
[1] |
WASHER-HARDENED
|
|
| 19. |
S391-110190
|
[1] |
SHIM-ROUND(1.0T)
|
|
| 20. |
S391-100165
|
[1] |
SHIM-ROUND(1.0T)
|
|
| 21. |
S391-080135
|
[1] |
SHIM-ROUND(1.0T)
|
|
| 22. |
S391-110180
|
[1] |
SHIM-ROUND(1.0T)
|
|
| 23. |
S017-16025D
|
[1] |
BOLT-HEX
|
|
| 24. |
61N8-19040
|
[2] |
STOPPER-PIN
|
|
| 25. |
S017-242206
|
[2] |
BOLT-HEX
|
|
| 26. |
S205-24100B
|
[4] |
NUT-HEX
|
|
| 27. |
S390-120200A
|
[1] |
SHIM-ROUND(0.5T)
|
|
| 28. |
S390-120220A
|
[1] |
SHIM-ROUND(0.5T)
|
|
