纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (05-020) - COOLER ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
634 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PH20M00019F1 | [1] | COOLER | KOBCOOLER ASSY Superseded by part number: PH20M00016F1 |
| 1. | PH20M00019S001 | [1] | CASE ASSY, UNIT | |
| 2. | PH20M00019S002 | [1] | PANEL ASSY. | KOBPANEL ASSY, UNIT |
| 3. | PH20M00019S003 | [1] | BOX ASSY, UNIT | |
| 4. | PH20M00019S004 | [1] | CASE ASSY, BLOWER | |
| 5. | PH20M00019S005 | [2] | COVER | |
| 6. | PH20M00019S006 | [1] | CONTROL PANEL | |
| 7. | PH20M00019S007 | [2] | CAP | |
| 8. | PH20M00019S008 | [1] | GROMMET | KOBGROMMET |
| 9. | PH20M00019S009 | [2] | CAB FILTER | KOB |
| 10. | PH20M00019S010 | [1] | PACKING | |
| 11. | PH20M00019S011 | [2] | PACKING | |
| 12. | PH20M00019S012 | [2] | PACKING | |
| 13. | PH20M00019S013 | [1] | ADIABATIC | |
| 14. | PH20M00019S014 | [1] | ADIABATIC | |
| 15. | PH20M00019S015 | [1] | ADIABATIC | |
| 16. | PH20M00019S016 | [1] | ADIABATIC | |
| 17. | PH20M00019S017 | [1] | ADIABATIC | |
| 18. | PH20M00019S018 | [1] | ADIABATIC | |
| 19. | PH20M00019S019 | [1] | ADIABATIC | |
| 20. | PH20M00019S020 | [1] | ADIABATIC | |
| 21. | PH20M00019S021 | [1] | ADIABATIC | |
| 22. | PH20M00019S022 | [1] | BRACKET | |
| 23. | PH20M00019S023 | [1] | SUPPORT | |
| 24. | PH20M00019S024 | [1] | TUBE | KOBTUBE |
| 25. | PH20M00019S025 | [1] | ELECTRIC MOTOR | KOBMOTOR ASSY, BLOWER |
| 26. | PH20M00019S026 | [1] | VALVE | KOB |
| 27. | PH20M00019S027 | [1] | SWITCH | KOBPUSH SWITCH |
| 28. | PH20M00019S028 | [1] | AMPLIFIER | KOBTHERMO AMPLIFIER |
| 29. | YT20M00004S003 | [1] | THERMOSTAT | KOB |
| 30. | YJ20M00013S033 | [1] | RESISTOR | KOBRESISTOR |
| 31. | PH20M00019S031 | [1] | THERMOSTAT | KOBTHERMO |
| 32. | PH20M00019S032 | [1] | HARNESS | KOBHARNESS ASSY |
| 33. | PH20M00019S033 | [1] | SPRING | KOBSPRING |
| 34. | PH20M00019S034 | [1] | DAMPER | KOBDAMPER |
| 35. | PH20M00019S035 | [3] | RELAY | KOBRELAY |
| 36. | PH20M00019S036 | [1] | EVAPORATOR | KOBEVAPORATOR |
| 37. | YT20M00004S066 | [2] | CAPSCREW | KOBSCREW CAP |
| 38. | 24100U1188S8 | [2] | SPACER | KOBSPACER |
| 39. | GB20M00008S069 | [3] | CLIP | KOBCLIP |
| 40. | YT20M00004S006 | [2] | HOLDER | KOBSENSOR |
| 41. | 2480U122S5 | [1] | CLAMP | KOBCLAMP |
| 42. | PH20M00019S042 | [1] | NAME PLATE | |
| 43. | PH20M00019S043 | [1] | NAME PLATE | |
| 44. | PH20M00019S044 | [1] | SWITCH | KOBSWITCH |
| 45. | PH20M00019S045 | [1] | O-RING | KOBO-RING |
| 46. | PH20M00019S046 | [6] | SCREW | KOBMACHINE SCREW |
| 47. | 2480U170S49 | [24] | SCREW | KOBMACHINE |
| 48. | PH20M00019S048 | [15] | SCREW | KOBMACHINE SCREW |
| 49. | PH20M00019S049 | [9] | SCREW | KOBMACHINE SCREW |
| 50. | PH20M00019S050 | [1] | BOLT | KOBMACHINE SCREW |
| 51. | PH20M00019S051 | [1] | LEVER | |
| 52. | PH20M00019S052 | [1] | NUT | |
| 53. | PH20M00019S053 | [1] | SPRING, WASHER | |
