神钢零件查询(K912A) - EXCAVATOR BTW LC-2003 - LC-2016 (1/85-12/03) (06-005) - ENGINE ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
458 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LC251-001 | [1] | FOR STD | |
| 1. | 2451U369F1 | [1] | ENGINE | |
| . . | LC252-001 | [1] | FOR EXTREME HEAT | |
| 2. | 2451U369F2 | [1] | ENGINE ASSY | ENGINE ASSY |
| 2-1. | 24100P928F1 | [1] | ELEMENT ASSY ASSY | ELEMENT ASSY ASSY |
| 2-1A. | 2446Z147S4 | [1] | AIR FILTER | HIT Superseded by part number: 87682968 |
| 2-1B. | 2446Z147S5 | [1] | NUT | KOBASSY |
| . . | LC253-001 | [1] | FOR COLD REGIONS OPT-2 | |
| 3. | 2451U369F3 | [1] | ENGINE | |
| . . | LC254-001 | [1] | FOR COLD REGIONS OPT-3 | |
| 4. | 2451U369F4 | [1] | ENGINE | |
| . . | LC256-001 | [1] | FOR COLD REGIONS OPT-3 | |
| 5. | 2451U369F5 | [1] | ENGINE | ENGINE |
| 5-1. | 24100P928F1 | [1] | ELEMENT ASSY | ELEMENT ASSY |
| 5-1A. | 2446Z147S4 | [1] | AIR FILTER | HIT Superseded by part number: 87682968 |
| 5-1B. | 2446Z147S5 | [1] | NUT | KOBASSY |
| . . | LC257-001 | [1] | TURBO, COMPENSATE | |
| 6. | 2451U372F1 | [1] | ENGINE | ENGINE |
| 6-1. | 24100P928F1 | [1] | ELEMENT ASSY | ELEMENT ASSY |
| 6-1A. | 2446Z147S4 | [1] | AIR FILTER | HITELEMENT, INNER Superseded by part number: 87682968 |
| 6-1B. | 2446Z147S5 | [1] | NUT | KOBASSY |
