神钢零件查询(K912A) - EXCAVATOR BTW LC-2003 - LC-2016 (1/85-12/03) (06-007) - RADIATOR ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
344 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2452U287F1 | [1] | RADIATOR ASSY | RADIATOR ASSY |
| 1. | 2452U287S1 | [1] | CORE ASSY, RADIATOR | CORE ASSY, RADIATOR |
| 2. | 2452U287S2 | [1] | TANK ASSY | |
| 3. | 2452U287S3 | [1] | TANK ASSY | |
| 4. | 2452U287S4 | [1] | PLATE ASSY | |
| 5. | 2452U287S5 | [1] | PLATE ASSY | |
| 6. | 2452U287S6 | [2] | PACKING | PACKING |
| 7. | 2452U287S7 | [4] | PACKING | PACKING |
| 8. | 2452U287S8 | [2] | PACKING | PACKING |
| 9. | 2452U287S9 | [52] | CAPSCREW | |
| 10. | 2452U367S18 | [68] | LOCK WASHER | |
| 11. | 2452U287S11 | [52] | NUT | |
| 12. | 2452U287S12 | [40] | CAPSCREW | |
| 13. | 2452U287S13 | [40] | LOCK WASHER | |
| 14. | 2452U287S14 | [1] | CAP | KOB |
| 16. | 2452U183S5 | [1] | PLUG | KOBDRAIN |
| 17. | 2452U287S17 | [1] | HOSE | KOB |
| 18. | 2452U287S18 | [1] | GUARD | KOB |
| 19. | 2452U287S19 | [2] | PACKING | KOB |
| 20. | 2452U287S20 | [16] | BOLT | |
| 22. | 2452U287S22 | [1] | OIL COOLER ASSY | OIL COOLER ASSY |
| 23. | 2452U287S23 | [2] | PACKING | KOB |
| 26. | 2452U287S26 | [16] | WASHER | KOBPLAIN Superseded by part number: ZW16X10000 |
| 27. | NSS | [1] | NOT SOLD SEPARAT | CONNAME-PLATE |
| . . | 2452U287R100 | [1] | RADIATOR | KOBCONSISTS OF REF 1,2,3,4,5,6,7,8,9,10,ll,12 13,14,16,17 |
