纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (06-008) - NAME PLATE INSTAL, P/N PW22T00085F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
146 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW22T00085F1 | [1] | LABEL | KOBName Plate Instal |
| 1. | PV20T01008P1 | [1] | WARNING DECAL | KOBWarning, Open or Close the door keeping machine horizontal and loack it securely |
| 2. | YN20T01416P1 | [1] | CAUTION DECAL | KOBCaution, Falling front window can cause injury (no picture) |
| 3. | PH20T01018P1 | [2] | WARNING DECAL | KOBBreak back glass, Located on inside of rear glass |
| 4. | PM20T01035P1 | [1] | LABEL | KOBCaution, Falling front window can cause injury (with picture) |
| 10. | PW20T01092P1 | [1] | LABEL | KOBTop Guard, This machine structure is manufactured based on.. |
