纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (06-012) - NAME PLATE INSTAL, P/N PX22T00072F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
646 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW22T00172F1 | [1] | LABEL | KOBNAME PLATE INSTAL |
| 1. | PW20T01133P1 | [1] | LABEL | KOBRotary Multi Control Lever-Lock Position |
| 2. | YN20T01214P1 | [1] | LABEL | KOBDanger, Stop the engine at time of changeover |
| 3. | YN20T01476P1 | [1] | LABEL | KOBDecal, Control location and positions |
| 4. | YN20T01475P1 | [1] | LABEL | KOBHOLDER |
| 5. | YN20T01039P1 | [1] | WARNING DECAL | KOBWarning, This machine equipped with a rotary mulit-control valve |
