凯斯零件查询(LB434S) - BALER (9/12-) (88.055.008[01]) - DIA KIT: MOISTURE SENSOR - C084 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
830 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84427548
|
[1] |
DIA KIT, HARVESTER
|
ZED
Incl 2 - 16 Superseded by part number: 47510814
|
| 2. |
84597957
|
[1] |
CONTROL UNIT
|
ZED
|
| 3. |
84598487
|
[1] |
WIRE HARNESS
|
ZED
|
| 4. |
84575870
|
[4] |
SPACER,10mm ID x 16mm OD x 25mm L
|
ZED
Superseded by part number: 84062460
|
| 5. |
84598486
|
[1] |
WIRE HARNESS
|
ZED
|
| 6. |
87395156
|
[2] |
REGULATING SYSTEM
|
ZED
|
| 7. |
86625036
|
[1] |
CLAMP,12.7mm, Coat, 8.7mm Bolt Hole, P Type
|
FAR
|
| 8. |
87395158
|
[1] |
GUARD
|
ZED
|
| 9. |
87395159
|
[1] |
GUARD
|
ZED
|
| 10. |
322358
|
[20] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 11. |
366046
|
[8] |
CARRIAGE BOLT,Sq Nk, M8 x 1.25 x 80mm, Cl 8.8
|
WIN
Superseded by part number: 120040
|
| 12. |
9706690
|
[20] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 13. |
120107
|
[4] |
BOLT,Hex, M8 x 1.25 x 50mm, Cl 8.8, Full Thd
|
ZED
Superseded by part number: 87015731
|
| 14. |
87380352
|
[1] |
ELEC CONNECTOR
|
ZED
|
| 15. |
86566989
|
[24] |
CABLE TIE,208mm L
|
ZED
|
| 16. |
47467782
|
[1] |
MOUNTING PLATE
|
ZED
|
