纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (07-004) - VALVE ASSY, CONTROL, (SUPPLY & STRAIGHT TRAVEL) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
912 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PX30V00050F1 | [1] | VALVE | KOBASSY, CONTROL |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONBODY |
| 3. | PX30V00050S001 | [1] | SEAT | KOB |
| 4. | PW30V01013S013 | [1] | SPRING | KOB |
| 5. | PW30V01009S002 | [2] | POPPET | KOB |
| 6. | PH30V00014S013 | [2] | SPRING | KOB |
| 7. | ZD12P01100 | [2] | O-RING | KOB |
| 8. | PW30V01009S005 | [2] | PLUG | KOB |
| 9. | PW30V01008S011 | [2] | O-RING | KOB |
| 10. | PM30V00027S015 | [1] | COVER | KOB |
| 11. | PM30V00021S014 | [2] | SCREW | KOB |
| 12. | PX30V00050S012 | [1] | PLUG | KOB |
| 13. | PX30V00050S013 | [1] | O-RING | KOB |
| 14. | PX30V00050S014 | [1] | PISTON | KOB |
| 15. | ZD12P00600 | [1] | O-RING | KOB |
| 16. | PX30V00050S016 | [1] | CAP | KOB |
| 17. | 2436U1317S22 | [1] | PLUG | KOB |
| 18. | PX30V00050S018 | [1] | ORIFICE | KOB |
| 19. | PX30V00050S019 | [1] | FILTER | KOB |
| 20. | ZS23C05030 | [3] | CAPSCREW,Hex Socket Head, M5 x 30mm | KOBSCREW CAP |
| 21. | PR22V00004F6 | [1] | VALVE | KOBASSY, RELIEF, SEE FIG. 07-015 |
