神钢零件查询(K916LC) - EXCAVATOR ASN YS0119 (1/87-12/03) (08-003) - GUARD ASSY, VANDALISM Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
529 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J8437F1 | [1] | GUARD ASSY, VANDALISM | |
| 1. | 2421N121 | [1] | BOX | |
| 2. | 2414R237 | [1] | GUARD | GUARD |
| . . | 2414R236 | [1] | GUARD | GUARD |
| 4. | 2414R242 | [1] | GUARD | KOB |
| 5. | 2414R240 | [1] | GUARD | KOB |
| 6. | 2414R245 | [1] | GUARD | GUARD |
| 7. | 2414R244 | [1] | GUARD | GUARD |
| 8. | 2414R243 | [1] | GUARD | GUARD |
| 9. | 2414R239 | [1] | GUARD | GUARD |
| 10. | 2414R241 | [1] | GUARD | GUARD |
| 11. | 2414R238 | [1] | GUARD | GUARD |
| 12. | ZS18C12020 | [4] | SCREW,Hex, M12 x 20mm | KOBM12x1.75x20mm |
| 13. | ZW26X12000 | [4] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 14. | ZW16X12000 | [4] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 15. | 2414P5517 | [1] | REWORK, BOX TOOL | |
| 17. | ZS18C08012 | [6] | SCREW,Hex, M8 x 12mm | KOBM08x1.25x12mm |
| 18. | ZW26X08000 | [8] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| . . | 24100J8437F2 | [1] | GUARD ASSY, VANDALISM | |
| 3. | 2414R236 | [1] | GUARD | GUARD |
| 16. | 2422P924 | [1] | REWORK, SIDE-DECK | |
