纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (07-025) - SPRING ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
635 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PX10V01008F1 | [1] | SPRING | KOB |
| 1. | PX10V01008S001 | [1] | SEAT | KOB |
| 2. | PX10V01008S002 | [1] | SEAT | KOB |
| 3. | PX10V01008S003 | [1] | COVER | KOB |
| 4. | PY10V01004S004 | [1] | ADJUSTMENT SCREW | KOB |
| 5. | PX10V01008S005 | [1] | SPRING | KOB |
| 6. | PX10V01008S006 | [1] | SPRING | KOB |
| 7. | ZD11P03000 | [1] | O-RING | KOB |
| 8. | ZS23C08030 | [2] | SCREW,Hex Socket Head, M8 x 30mm | KOBCAP Superseded by part number: ZS28C08030 |
| 9. | PY10V01004S009 | [1] | NUT | KOB |
| 10. | PX10V01008S010 | [1] | GUIDE | KOB |
| 34. | PX10V01008S034 | [2] | SHIM,1.0mm Thk | KOB |
| 44. | PX10V01008S044 | [2] | SHIM,0.5mm Thk | KOB |
| 54. | PX10V01008S054 | [2] | SHIM,0.3mm Thk | KOB |
