纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (07-029) - PUMP ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
672 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PX10V00012F1 | [1] | HYDRAULIC PUMP | KOBPUMP ASSY |
| 1. | PX10V01004F1 | [1] | SHAFT ASSY. | KOBASSY, SEE FIG. 07-021 |
| 2. | PX10V01005F1 | [1] | BLOCK ASSY. | KOBASSY, SEE FIG. 07-022 |
| 3. | PX10V01006F1 | [1] | ROTATOR | KOBASSY, SEE FIG. 07-023 |
| 4. | PX10V01007F1 | [1] | COVER ASSY | KOBASSY, SEE FIG. 07-024 |
| 5. | PX10V01008F1 | [1] | SPRING | KOBASSY, SEE FIG. 07-025 |
| 7. | PX10V00014F1 | [1] | PUMP | KOBASSY, GEAR, SEE FIG. 07-028 |
| 8. | PX10V01009F1 | [1] | HOUSING | KOBHOUSING ASSY, SEE FIG. 07-030 Superseded by part number: PX10V00012F1 |
| 9. | PX10V00015F1 | [1] | PUMP | KOBASSY, SEE FIG. 07-026 |
| 11. | PM10V00013S011 | [1] | LABEL | KOB |
| 17. | PY10V00007S017 | [1] | BREATHER | KOB |
| 18. | 2441U720S49 | [1] | PLUG | KOB |
