凯斯零件查询(LBX331R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (8/01-12/03) (08.009[01]) - LOWER SHIELDS, SINGLE AXLE, LH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
870 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84806605
|
[1] |
DOOR
|
ZED
|
| 2. |
84806607
|
[1] |
SUPPORT
|
ZED
|
| 3. |
84806612
|
[1] |
GUARD
|
ZED
|
| 4. |
84806610
|
[1] |
REAR FENDER
|
ZED
|
| 5. |
84806609
|
[1] |
GUARD
|
ZED
|
| 6. |
811-8020
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 7. |
80322358
|
[1] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 9. |
80336455
|
[1] |
PLUG
|
ZED
Superseded by part number: 336455
|
| 8. |
89706690
|
[1] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
