神钢零件查询(K935) - EXCAVATOR BTW L70106 - L70166, LU0067 (1/76-12/03) (07-003) - TOOL ASSY, P/N 24100P467F3 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
822 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P467F3 | [1] | TOOL ASSY CONSISTS OF REF. 1 TO 54 | |
| 1. | 21Z71D7 | [1] | HAMMER | |
| 2. | 2421T8 | [1] | TIGHTENER | KOB |
| 3. | 4027R1 | [1] | COMPLETE TOOL BOX | KOB |
| 4. | ZT12B08010 | [1] | SPANNER | |
| 5. | ZT12B12014 | [1] | SPANNER | |
| 6. | ZT12B13017 | [1] | WRENCH, PIPE | WRENCH, PIPE |
| 7. | ZT12B19022 | [1] | WRENCH, PIPE | WRENCH, PIPE |
| 8. | ZT12B24027 | [1] | WRENCH, PIPE | WRENCH, PIPE |
| 9. | ZT12B30032 | [1] | WRENCH | WRENCH |
| 10. | ZT12A36000 | [1] | SEAT BACK | KOBSpanner, 36mm |
| 11. | ZT12A46000 | [1] | POINT | KOB46mm |
| 12. | ZT12A41000 | [1] | ADJUSTING WRENCH | KOBSpanner, 41mm |
| 13. | ZT12A50000 | [1] | POINT | KOBSpanner -- 50mm Long (1-31/32 in) |
| 14. | ZT12A55000 | [1] | SPECIAL WRENCH | KOBSpanner -- 55mm |
| 15. | ZT22A05000 | [1] | KEY | KOBScrew -- 05mm |
| 16. | ZT22A06000 | [1] | KEY, SCREW 06mm | KEY, SCREW 06mm |
| 17. | ZT22A08000 | [1] | KEY | KOBScrew -- 08mm |
| 18. | ZT22A10000 | [1] | KEY | KOB10mm |
| 19. | ZT22A12000 | [1] | KEY, SCREW 12mm | KEY, SCREW 12mm |
| 20. | ZT22A14000 | [1] | KEY | KOB14mm |
| 21. | ZT22A17000 | [1] | KEY, SCREW 17mm | KEY, SCREW 17mm |
| 22. | ZT31A17000 | [1] | SOCKET | KOB |
| 23. | ZT31A19000 | [1] | SOCKET | KOB |
| 24. | ZT31A22000 | [1] | SOCKET | KOB |
| 25. | ZT31A24000 | [1] | SOCKET | KOB |
| 26. | ZT31A30000 | [1] | SOCKET | KOB |
| 28. | ZT12D20000 | [1] | WRENCH, ADJUST 24mm Maximum | WRENCH, ADJUST 24mm Maximum |
| 29. | ZT12D30000 | [1] | WRENCH, ADJUST 34mm Maximum | WRENCH, ADJUST 34mm Maximum |
| 30. | ZT41A06100 | [1] | DRIVER | DRIVER |
| 31. | ZT41A09200 | [1] | DRIVER | |
| 32. | R21P0004 | [1] | WEAR, WORKING | |
| 33. | 4021Z18 | [1] | HOLDER, KEY | |
| 34. | ZT51A20000 | [1] | PLIERS | KOB |
| 35. | ZT31D13150 | [1] | BAR | KOB |
| 36. | ZT31B13250 | [1] | HANDLE | KOB |
| 37. | ZT41B20100 | [1] | DRIVER | DRIVER |
| 38. | 2421R107 | [1] | GREASE GUN | KOB Superseded by part number: KAP2421R107 |
| 39. | R18P0073 | [1] | HOSE | KOB |
| 40. | 2421T119 | [1] | DIVIDER | DIVIDER |
| 41. | 2421R118 | [1] | WRENCH WRENCH | |
| 42. | 2421U4F2 | [1] | WRENCH | |
| 44. | 24100T89F1 | [1] | HYD CONNECTOR | KOBCONSISTS OF REF. 44-1 AND 44-2 |
| 44-1. | 2444Z1779 | [1] | ADAPTER | ADAPTER |
| 44-2. | 2444T862 | [1] | REDUCER | KOB |
| 45. | 2444R532D2 | [2] | HOSE | KOBINCL. REF. 45-3 |
| 45-3. | 2444R532S3 | [2] | DUST CAP | |
| 54. | 2421Z208D2 | [1] | ADAPTER | |
