凯斯零件查询(LBX331R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (8/01-12/03) (11.01[01]) - WHEELS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
429 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84074614
|
[2] |
TYRE/TIRE
|
ZED
|
| 1. |
84074615
|
[2] |
TYRE/TIRE
|
ZED
|
| 1. |
84074616
|
[4] |
TYRE/TIRE
|
ZED
|
| 1. |
84100453
|
[4] |
TYRE/TIRE
|
ZED
|
| 1. |
84429638
|
[4] |
TYRE/TIRE
|
ZED
|
| 2. |
84607763
|
[2] |
RIM
|
ZED
20.00x22.5
|
| 2. |
84607761
|
[2] |
RIM
|
ZED
24.0x22.5
|
| 2. |
84607765
|
[2] |
RIM
|
ZED
16.0x17
|
| 2. |
84607759
|
[4] |
RIM
|
ZED
16.0x17
|
| 3. |
80395448
|
[2] |
VALVE STEM
|
ZED
Superseded by part number: 86507333
|
| 4. |
89837788
|
[2] |
NUT
|
ZED
M24 Superseded by part number: 9837788
|
| 5. |
89838996
|
[2] |
COTTER PIN
|
ZED
Superseded by part number: 9838996
|
| 6. |
84074953
|
[2] |
SHAFT
|
ZED
|
| 7. |
84607730
|
[2] |
WHEEL ASSY,370mm OD x 160mm W
|
ZED
, Serial Range: (8-11)
|
| 8. |
80443898
|
[4] |
BALL BEARING
|
ZED
Superseded by part number: 84188095
|
| 9. |
84807399
|
[2] |
RIM
|
ZED
|
| 10. |
84429037
|
[2] |
TIRE TUBE
|
ZED
|
| 11. |
84429038
|
[2] |
TYRE/TIRE
|
ZED
|
| 12. |
84607477
|
[2] |
TIRE TUBE
|
ZED
|
| 12. |
84607476
|
[2] |
TIRE TUBE
|
ZED
|
