凯斯零件查询(LBX331R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (8/01-12/03) (12.04[01]) - JACK Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
368 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84041156
|
[1] |
JACK
|
ZED
, Serial Range: (2-20)
|
| 2. |
84814120
|
[1] |
TUBE
|
ZED
|
| 3. |
84814119
|
[1] |
TUBE
|
ZED
|
| 4. |
84400422
|
[1] |
THREADED ROD
|
ZED
|
| 5. |
84400423
|
[1] |
COVER
|
ZED
|
| 6. |
84400424
|
[1] |
HANDLE
|
ZED
|
| 7. |
84400425
|
[1] |
BALL BEARING
|
ZED
|
| 8. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Washer
|
| 9. |
84400426
|
[1] |
GEAR
|
ZED
Z=14
|
| 10. |
84400427
|
[1] |
GEAR
|
ZED
Z=32
|
| 11. |
80130050
|
[1] |
ROLL PIN
|
ZED
Superseded by part number: 300872
|
| 12. |
80300871
|
[1] |
COTTER PIN
|
ZED
|
| 13. |
84400428
|
[1] |
PIN
|
ZED
|
| 15. |
80450300
|
[1] |
COTTER PIN
|
ZED
Superseded by part number: 450300
|
| 16. |
80412014
|
[1] |
LUBE NIPPLE
|
ZED
Superseded by part number: 87563868
|
| 17. |
80043442
|
[4] |
NUT,M8 x 1.25, Cl 8
|
ZED
Superseded by part number: 82034883
|
| 18. |
80322358
|
[4] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 19. |
84400429
|
[2] |
BUSHING
|
ZED
|
| 20. |
84814121
|
[1] |
TUBE
|
ZED
|
