| 1. |
100020
|
[2] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 2. |
80140048
|
[2] |
WASHER
|
ZED
16MM Superseded by part number: 140048
|
| 3. |
80140020
|
[2] |
WASHER
|
ZED
16MM Superseded by part number: 80299
|
| 4. |
80310146
|
[4] |
FLANGE
|
ZED
Superseded by part number: 310146
|
| 5. |
84039072
|
[2] |
DRIVEN SPROCKET
|
ZED
|
| 6. |
80443898
|
[2] |
BALL BEARING
|
ZED
Superseded by part number: 84188095
|
| 7. |
80120100
|
[6] |
BOLT,M6 x 1 x 20mm
|
ZED
Superseded by part number: 120100
|
| 8. |
80322357
|
[6] |
LOCK WASHER,Belleville, M6
|
ZED
6MM Superseded by part number: 322357
|
| 10. |
89509425
|
[2] |
RING
|
ZED
Superseded by part number: 9509425
|
| 11. |
80378245
|
[1] |
WASHER
|
ZED
Superseded by part number: 378245
|
| 12. |
89602988
|
[2] |
WASHER
|
ZED
Superseded by part number: 9602988
|
| 13. |
80120047
|
[2] |
BOLT
|
ZED
M16x70 Superseded by part number: 120047
|
| 14. |
80370006
|
[1] |
SNAP RING
|
ZED
Superseded by part number: 370006
|
| 15. |
80442203
|
[1] |
WASHER
|
ZED
Superseded by part number: 442203
|
| 16. |
84038911
|
[1] |
KEY
|
ZED
|
| 17. |
84078102
|
[1] |
DRIVEN SPROCKET
|
ZED
Superseded by part number: 84818575
|
| 18. |
84038889
|
[1] |
DISC
|
ZED
Superseded by part number: 84818529
|
| 19. |
80374895
|
[1] |
CARRIAGE BOLT
|
ZED
M12x25 Superseded by part number: 374895
|
| 20. |
80140046
|
[1] |
WASHER
|
ZED
12MM Superseded by part number: 140046
|
| 21. |
89706685
|
[1] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 22. |
89837215
|
[2] |
FLANGE
|
ZED
Superseded by part number: 86620027
|
| 23. |
80552945
|
[1] |
BEARING ASSY
|
ZED
Superseded by part number: 412441
|
| 24. |
84068639
|
[1] |
SHAFT
|
ZED
|
| 25. |
86517808
|
[3] |
SCREW,M12 x 25mm
|
ZED
M12x30 Superseded by part number: 300388
|
| 26. |
84074957
|
[1] |
DISC
|
ZED
|
| 27. |
84607738
|
[1] |
SUPPORT
|
ZED
|
| 29. |
80322358
|
[2] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 30. |
80308761
|
[2] |
SCREW,M8 x 25mm
|
ZED
M8x25 Superseded by part number: 308761
|
| 31. |
84038906
|
[1] |
CLUTCH
|
ZED
, Serial Range: (32-46) Superseded by part number: 87648382, 87364752
|
| 32. |
84043419
|
[1] |
FLANGE
|
ZED
|
| 33. |
84026625
|
[4] |
DISC
|
ZED
|
| 34. |
84004296
|
[1] |
DISC
|
ZED
|
| 35. |
84004297
|
[1] |
CLUTCH PLATE
|
ZED
|
| 36. |
84004298
|
[2] |
CIRCLIP
|
ZED
|
| 37. |
84004299
|
[2] |
RING
|
ZED
Superseded by part number: 87731760
|
| 38. |
84004300
|
[1] |
THRUST PLATE
|
ZED
|
| 39. |
321204
|
[1] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 40. |
84043420
|
[1] |
HUB
|
ZED
|
| 41. |
84004301
|
[3] |
REPAIR KIT
|
ZED
|
| 42. |
84004304
|
[1] |
CLUTCH PLATE,76.2mm ID x 157.23mm OD x 9.53mm Thk
|
ZED
|
| 43. |
84058571
|
[1] |
SPRING-DISC
|
ZED
|
| 44. |
84004306
|
[1] |
WASHER
|
ZED
|
| 45. |
84004307
|
[1] |
HOUSING
|
ZED
|
| 46. |
84058570
|
[1] |
BELLEVILLE WASHER
|
ZED
|
| 47. |
84807354
|
[1] |
CHAIN,Roller, 122 Links x 19.05mm = 2324.1mm
|
ZED
(48,49)
|
| 48. |
80025808
|
[1] |
LINK CHAIN
|
ZED
Superseded by part number: 86595251
|
| 49. |
80165590
|
[1] |
CONNECTING LINK
|
ZED
Superseded by part number: 241-1316
|
| 28. |
89706690
|
[2] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 9. |
15896221
|
[1] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
