| 1. |
84607792
|
[1] |
AUGER
|
ZED
RH
|
| 2. |
84607791
|
[1] |
AUGER
|
ZED
LH
|
| 3. |
80140046
|
[1] |
WASHER
|
ZED
12MM Superseded by part number: 140046
|
| 4. |
80120044
|
[4] |
BOLT
|
ZED
M12x30, Serial Range: -C287 Superseded by part number: 120044
|
| 4. |
80328754
|
[4] |
SCREW
|
ZED
M12x40, Start Serial: D288 Superseded by part number: 328754
|
| 5. |
80140045
|
[1] |
WASHER
|
ZED
10MM Superseded by part number: 140045
|
| 6. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 7. |
84607907
|
[1] |
FRAME
|
ZED
Superseded by part number: 100038, 43158, 87663292, 84025509, 87535752, 9832679, 86500688, 84162041, 370006, 322357, 140015, 120100, 87335294, 84162039
|
| 7. |
84607908
|
[1] |
FRAME
|
ZED
Superseded by part number: 84162041, 87616401, 86500688, 322357, 87335294, 87535752, 84025509, 43158, 140015, 370006, 120100, 9832679, 84162039, 100038
|
| 8. |
84607767
|
[1] |
ANGLE
|
ZED
LH
|
| 8. |
84607768
|
[1] |
ANGLE
|
ZED
RH
|
| 9. |
86512446
|
[6] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 10. |
84607735
|
[2] |
ARM
|
ZED
|
| 11. |
80300662
|
[2] |
BOLT
|
ZED
M12x70 Superseded by part number: 300662
|
| 12. |
89504194
|
[2] |
BOLT
|
ZED
M12x85 Superseded by part number: 84818450
|
| 13. |
84041968
|
[2] |
LOCKING PLATE
|
ZED
|
| 14. |
89706685
|
[6] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 15. |
84607772
|
[1] |
GUARD
|
ZED
|
| 16. |
84607781
|
[1] |
GUARD
|
ZED
Superseded by part number: 84274384
|
| 17. |
86511478
|
[1] |
BOLT,Hex Serr, M8 x 1.25 x 16mm
|
ZED
|
| 18. |
84000002
|
[2] |
CHAIN
|
ZED
|
| 19. |
80140084
|
[4] |
WASHER
|
ZED
Superseded by part number: 140084
|
| 20. |
84039278
|
[2] |
COVER PLATE
|
ZED
|
| 21. |
80378245
|
[2] |
WASHER
|
ZED
12MM Superseded by part number: 378245
|
| 22. |
80412126
|
[2] |
LOCK NUT
|
ZED
M12 Superseded by part number: 412126
|
| 23. |
84078480
|
[1] |
PLATE
|
ZED
|
| 23. |
84074341
|
[1] |
PLATE
|
ZED
|
| 24. |
80412607
|
[3] |
PIN
|
ZED
Superseded by part number: 412607
|
| 25. |
80130004
|
[3] |
COTTER PIN
|
ZED
Superseded by part number: 130004
|
| 26. |
84078667
|
[1] |
SHAFT
|
ZED
|
| 26. |
84053189
|
[1] |
SHAFT
|
ZED
|
| 27. |
43138
|
[2] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
|
NH
|
| 28. |
84041969
|
[1] |
PLATE
|
ZED
|
