| 1. |
84074241
|
[1] |
FRAME
|
ZED
|
| 1. |
84074378
|
[1] |
FRAME
|
ZED
|
| 2. |
84041706
|
[1] |
ROLLER
|
ZED
|
| 3. |
80370024
|
[1] |
CIRCLIP
|
ZED
Superseded by part number: 370024
|
| 4. |
80300313
|
[1] |
BEARING ASSY
|
ZED
Superseded by part number: 86629499
|
| 5. |
80300645
|
[1] |
CIRCLIP
|
ZED
Superseded by part number: 300645
|
| 6. |
84074190
|
[1] |
ROD
|
ZED
|
| 6. |
84056870
|
[1] |
ROD
|
ZED
|
| 7. |
80378245
|
[1] |
WASHER
|
ZED
12MM Superseded by part number: 378245
|
| 8. |
80130045
|
[1] |
PIN
|
ZED
5x26 Superseded by part number: 130045
|
| 9. |
80151990
|
[1] |
SPRING
|
ZED
Superseded by part number: 151990
|
| 10. |
84056189
|
[1] |
PIN
|
ZED
|
| 11. |
84039459
|
[1] |
PIN,16mm OD
|
ZED
|
| 12. |
84043589
|
[1] |
SPRING
|
ZED
|
| 13. |
80140090
|
[1] |
WASHER
|
ZED
Superseded by part number: 140090
|
| 14. |
80333960
|
[1] |
ROLL PIN
|
ZED
Superseded by part number: 333960
|
| 15. |
80543043
|
[1] |
WASHER
|
ZED
Superseded by part number: 543043
|
| 16. |
80140046
|
[1] |
WASHER
|
ZED
12MM Superseded by part number: 140046
|
| 17. |
89706687
|
[1] |
SCREW
|
ZED
M12x30 Superseded by part number: 9706687
|
| 18. |
84056505
|
[1] |
KNIFE
|
ZED
|
| 18. |
84058219
|
[1] |
KNIFE
|
ZED
|
| 19. |
84056868
|
[1] |
COVER PLATE
|
ZED
|
| 20. |
84042270
|
[1] |
CANVAS
|
ZED
|
| 20. |
84074192
|
[1] |
CANVAS,400mm W x 940mm L
|
ZED
|
| 21. |
89850761
|
[1] |
PIN
|
ZED
Superseded by part number: 9850761
|
| 22. |
89511931
|
[1] |
ROLL PIN
|
ZED
3x26 Superseded by part number: 84818466
|
| 23. |
80378246
|
[3] |
WASHER
|
ZED
Superseded by part number: 378246
|
| 24. |
80412685
|
[3] |
COTTER PIN
|
ZED
Superseded by part number: 412685
|
| 25. |
80140048
|
[4] |
WASHER
|
ZED
16MM Superseded by part number: 140048
|
| 26. |
84807161
|
[1] |
HYDRAULIC CYLINDER,Double Acting, 25mm Rod, 120mm Stroke
|
ZED
|
| 27. |
84072937
|
[1] |
WIRE HARNESS
|
ZED
|
| 28. |
89501786
|
[1] |
PIN
|
ZED
|
| 29. |
80378247
|
[1] |
WASHER
|
ZED
20MM Superseded by part number: 378247
|
| 30. |
80412686
|
[1] |
COTTER PIN
|
ZED
Superseded by part number: 412686
|
| 31. |
80386215
|
[1] |
HYD CONNECTOR
|
ZED
Superseded by part number: 386215
|
| 32. |
80396162
|
[1] |
HYD CONNECTOR
|
ZED
Superseded by part number: 396162
|
| 33. |
89706685
|
[2] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 34. |
321204
|
[2] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 35. |
80043139
|
[2] |
BOLT,M10 x 25mm
|
ZED
Superseded by part number: 11106231
|
| 36. |
84043965
|
[1] |
HYDRAULIC HOSE
|
ZED
|
| 37. |
80292267
|
[1] |
BAND
|
ZED
|
| 38. |
80430356
|
[2] |
CLAMP
|
ZED
Superseded by part number: 430356
|
| 39. |
80431942
|
[1] |
SUPPORT
|
ZED
Superseded by part number: 84814948
|
| 40. |
80353308
|
[1] |
NUT
|
ZED
M6 Superseded by part number: 353308
|
| 41. |
80120056
|
[1] |
SCREW
|
ZED
M6x50 Superseded by part number: 120056
|
| 42. |
84039315
|
[1] |
SHAFT
|
ZED
|
| 42. |
84074191
|
[1] |
SHAFT
|
ZED
|
| 43. |
80170019
|
[2] |
KEY
|
ZED
14x9x40 Superseded by part number: 170019
|
| 44. |
80412202
|
[3] |
LOCK PIN
|
ZED
Superseded by part number: 412202
|
| 45. |
84039463
|
[2] |
LEVER
|
ZED
|
| 46. |
80058821
|
[1] |
WASHER
|
ZED
Superseded by part number: 58821
|
| 47. |
84039452
|
[2] |
SUPPORT
|
ZED
|
| 48. |
80443076
|
[1] |
LOCK WASHER
|
ZED
Superseded by part number: 84814169
|
| 49. |
84005527
|
[1] |
WASHER,46mm ID x 70mm OD x 1mm Thk
|
ZED
|
| 50. |
84068634
|
[1] |
LEVER
|
ZED
|
| 51. |
84068635
|
[1] |
PLATE
|
ZED
|
| 52. |
84041862
|
[1] |
CIRCLIP
|
ZED
|
| 53. |
84041936
|
[1] |
ROLLER,25mm OD x 15mm L
|
ZED
|
| 54. |
84043787
|
[1] |
PIN
|
ZED
Superseded by part number: 87652359
|
| 55. |
84607256
|
[1] |
TOOL
|
ZED
|
| 56. |
84038524
|
[1] |
SPRING,Compression, 1.26" OD x 13.39" L
|
ZED
|
| 57. |
84074189
|
[1] |
PROFILE
|
ZED
|
| 57. |
84068632
|
[1] |
PROFILE
|
ZED
|
| 58. |
84039309
|
[4] |
COVER PLATE
|
ZED
|
| 59. |
84039310
|
[2] |
HEX PLUG,44mm L
|
ZED
|
| 60. |
120104
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 61. |
80380840
|
[2] |
PIN
|
ZED
46x60x1 Superseded by part number: 380840
|
| 62. |
80043442
|
[1] |
NUT,M8 x 1.25, Cl 8
|
ZED
Superseded by part number: 82034883
|
| 63. |
84043973
|
[1] |
FRICTION WASHER,15mm ID x 21mm OD x 1.5mm Thk
|
ZED
|
| 64. |
84043966
|
[1] |
HYDRAULIC HOSE
|
ZED
|
| 65. |
84074330
|
[1] |
COVER PLATE
|
ZED
|
| 65. |
84045050
|
[1] |
COVER PLATE
|
ZED
|
| 66. |
84074329
|
[1] |
COVER PLATE
|
ZED
|
| 66. |
84045049
|
[1] |
COVER PLATE
|
ZED
|
| 67. |
100020
|
[4] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 68. |
80140045
|
[4] |
WASHER
|
ZED
10MM Superseded by part number: 140045
|
| 69. |
80372783
|
[1] |
KNOB
|
ZED
Superseded by part number: 372783
|
| 70. |
80140111
|
[2] |
WASHER
|
ZED
Superseded by part number: 84814900
|
| 71. |
84056934
|
[1] |
RACK
|
ZED
Superseded by part number: 84801665
|
| 72. |
80437424
|
[2] |
COTTER PIN
|
ZED
Superseded by part number: 437424
|
| 73. |
80043168
|
[4] |
BOLT
|
ZED
M16x40 Superseded by part number: 43168
|
| 74. |
80120044
|
[2] |
BOLT
|
ZED
M12x30 Superseded by part number: 120044
|
| 76. |
84042245
|
[1] |
FIXING PLATE
|
ZED
|
| 77. |
84042244
|
[1] |
FIXING PLATE
|
ZED
|
| 77. |
84074326
|
[1] |
FIXING PLATE
|
ZED
|
| 78. |
80140126
|
[1] |
WASHER
|
ZED
|
