神钢零件查询(K935) - EXCAVATOR BTW L70106 - L70166, LU0067 (1/76-12/03) (11-006) - CAB INST, G.M. ENG. MOUNT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
299 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J1835F4 | [1] | INSTAL, CAB, CONSISTS OF REF 2 TO 25 | |
| 2. | 2414T776C2 | [10] | COVER | COVER |
| 3. | 2416Z176D8 | [1] | SEAT, RUBBER | |
| 4. | 2416Z179 | [10] | RUBBER, CUSHION | RUBBER, CUSHION |
| 5. | 2418T3989D2 | [5] | SPACER | SPACER |
| 9. | ZN31C16015 | [5] | NUT | KOBM16x2.0mm |
| 10. | ZS11C10020 | [4] | CAPSCREW M10x1.50x20mm | CAPSCREW M10x1.50x20mm |
| 11. | ZS11C16110 | [5] | CAPSCREW M16x2.0x110mm | CAPSCREW M16x2.0x110mm |
| 12. | ZW22X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 16. | 24100J2049F1 | [1] | INSULATIOR ASSY | |
| 19. | 2427Z312 | [1] | MAT, FLOOR | MAT, FLOOR |
| 20. | 2427Z313 | [1] | MAT, FLOOR | MAT, FLOOR |
| 22. | NSS | [1] | NOT SOLD SEPARAT | CONCAB ASSY |
| 23. | 24100U159F1 | [1] | SEAT | SEAT |
| 24. | 2427R280 | [1] | MAT, FLOOR | |
| 25. | 2427R281 | [1] | MAT, FLOOR | |
