神钢零件查询(K935) - EXCAVATOR BTW L70106 - L70166, LU0067 (1/76-12/03) (11-013) - CONTROL ASSY, ENG, G.M.ENG.MOUNT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
710 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N1511F1 | [1] | CONTROL ASSY, ENGINE, CONSISTS OF REF 1 TO | |
| 1. | 2416P4813 | [1] | BRACKET | |
| 2. | 2406T1291 | [1] | LOCK | LOCK |
| 3. | R16T0403 | [1] | CLAMP | KOB |
| 4. | ZS11C06014 | [3] | SCREW,Hex, M6 x 14mm, Cl 4.8 | KOBM06x1.0x14mm Superseded by part number: ZS16C06014 |
| 3. | ZW22X06000 | [2] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 6. | 2432Z186D1 | [3] | CLIP | CLIP |
| 7. | 2432Z187 | [3] | RING, CLIP | RING, CLIP |
| 8. | ZN11C06005 | [2] | NUT | KOBNUT M06x1.0mm Superseded by part number: ZN18C06005 |
| 9. | ZW11X06000 | [1] | WASHER | KOBID 06.6 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 10. | ZP15K02020 | [1] | SPLIT PIN | KOB |
| 11. | ZW11X16000 | [2] | WASHER | KOBID 16 x OD 30 x Th 2.3mm |
