| . . | 24100J2647F1 | [1] | INSTAL,ELEC WIRE CONSISTS OF REF. 1 TO 25 | |
| 1. | B00P0001F1 | [1] | WIPER | KOBCONSISTS OF REF. 1-1 TO 1-5 |
| 1-1. | R79P0020D1 | [1] | WIPER MOTOR | KOB Superseded by part number: 2456R8D25 |
| 1-2. | R79P0022 | [1] | WIPER ARM | KOB |
| 1-3. | R79P0021 | [1] | WIPER BLADE | KOB Superseded by part number: 2488Z8D3 |
| 1-4. | ZS31C06010 | [6] | SCREW,Phillips Drive, Pan HD, M6 x 10mm | KOBM06x1.0x10mm |
| 1-5. | ZW22X06000 | [6] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 2. | 2456R123 | [2] | LIGHT | KOB |
| 3. | 2456R104 | [2] | LIGHT | LIGHT |
| 4. | B00P0002F1 | [1] | LIGHT ASSY CONSISTS OF REF. 4-1 TO 4-2 | LIGHT ASSY CONSISTS OF REF. 4-1 TO 4-2 |
| 4-1. | 4056R4F1 | [1] | LAMP | KOBCONSISTS OF REF. 4-1A AND 4-1G |
| 4-1A. | 4056R4 | [1] | LIGHT | KOB Superseded by part number: 4056R4F1 |
| 4-1G. | 4056Z19D1 | [1] | LIGHT | KOB |
| 4-2. | ZS31C03008 | [2] | SCREW,Phillips Drive, Pan HD, M3 x 8mm | KOBM03x0.5x08mm |
| 5. | 2479U142 | [1] | RELAY | KOB |
| 6. | R79P0075 | [1] | SPEAKER | SPEAKER |
| 7. | R16T0240 | [2] | SEAT. RUBBER | |
| 8. | B16P0158 | [2] | COVER | |
| 9. | B16T0081 | [6] | BRACKET | |
| 10. | ZN11C06005 | [8] | NUT | KOBNUT M06x1.0mm Superseded by part number: ZN18C06005 |
| 11. | ZN11C10008 | [8] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 12. | ZS11C10020 | [9] | CAPSCREW M10x1.50x20mm | CAPSCREW M10x1.50x20mm |
| 13. | R79P0076 | [1] | FRONT LAMP | FRONT LAMP |
| 14. | ZS31C06025 | [8] | SCREW,Phillips Drive, Pan HD, M6 x 25mm | KOBM06x1.0x25mm |
| 15. | 2432Z270 | [8] | CLAMP | KOB |
| 16. | ZW22X06000 | [14] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 17. | ZW22X10000 | [17] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 18. | R16T0063D3 | [1] | GROMMET | KOB |
| 19. | R16T0063D3 | [1] | GROMMET | KOB |
| 20. | 2432Z186D1 | [6] | CLIP | CLIP |
| 21. | 2432Z187 | [6] | RING, CLIP | RING, CLIP |
| 22. | ZS11C08020 | [4] | SCREW,Hex, M8 x 20mm, Cl 4.8 | KOBCAPTIVE WASHER SCREW CAPSCREW -- M08x1.25x20mm Superseded by part number: ZS18C08020 |
| 23. | ZW22X08000 | [4] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 24. | ZS11C10025 | [4] | CAP,Hex, M10 x 25mm, Cl 4.8 | KOBScrew -- M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 25. | ZS31C06016 | [6] | SCREW,Phillips Drive, Pan HD, M6 x 16mm | KOBM06x1.0x16mm |
