神钢零件查询(K935) - EXCAVATOR BTW L70106 - L70166, LU0067 (1/76-12/03) (04-002) - HYDR LINES, UPP, P/N 24100X619F4 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
343 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X619F4 | [1] | HYDR LINES UPP INCL. REF. 3 TO 55 | |
| 3. | 2436U341F3 | [1] | VALVE, CONTROL | VALVE, CONTROL |
| 4. | ZC37X50114 | [2] | CLAMP | |
| 5. | ZC35X50014 | [4] | | |
| 6. | R16T0175D3 | [16] | SPACER | SPACER |
| 8. | 2432T964 | [2] | CLAMP | |
| 9. | 2432T965 | [1] | CLAMP | |
| 10. | R16P0027D4 | [2] | CLAMP | KOB |
| 11. | ZC27X35014 | [8] | CLAMP | KOB |
| 12. | 2416T4878D3 | [1] | BLOCK, TAPPED | |
| 13. | 2416T4877 | [4] | BLOCK, TAPPED | |
| 16. | 2416T5240 | [1] | BRACKET | |
| 17. | 2416P3889 | [1] | BRACKET BRACKET | |
| 18. | 2416N1385 | [1] | BRACKET | |
| 20. | 2416T4892 | [3] | BRACKET | |
| 21. | 2416T4891 | [3] | BRACKET | |
| 22. | 2416P3893 | [1] | BRACKET | |
| 23. | ZS13C16070 | [4] | SCREW | KOBM16x2.0x70mm |
| 24. | ZS13C16065 | [2] | SCREW | KOBM16x2.0x65mm |
| 25. | ZS11C12090 | [3] | CAPSCREW | |
| 26. | ZS11C12085 | [12] | CAPSCREW | |
| 27. | ZS11C12070 | [2] | CAPSCREW | |
| 28. | ZS11C12065 | [10] | CAPSCREW | |
| 30. | ZS11C12035 | [4] | SCREW,Hex, M12 x 35mm, Cl 4.8 | KOBM12x1.75x35mm Superseded by part number: ZS18C12035 |
| 31. | ZS12C12030 | [2] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm Superseded by part number: ZS18C12030 |
| 32. | ZS23C12150 | [16] | CAPSCREW CAPSCREW | |
| 33. | ZN11C16013 | [8] | NUT | KOBM16x2.0mm |
| 34. | ZN11C12010 | [27] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 35. | ZW11X16000 | [8] | WASHER | KOBID 16 x OD 30 x Th 2.3mm |
| 36. | ZW11X12000 | [17] | WASHER | KOBID 12 x OD 24 x Th 2.3mm Superseded by part number: ZW16X12000 |
| 37. | ZW22X16000 | [14] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 38. | ZW22X12000 | [53] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 39. | ZW22X10000 | [3] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 43. | ZS11C16055 | [8] | CAPSCREW | |
| 44. | ZS13C12065 | [4] | SCREW | KOB Superseded by part number: ZS18C12065 |
| 45. | ZS12C10035 | [3] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm Superseded by part number: ZS18C10035 |
| 46. | 2436U341F4 | [1] | VALVE, CONTROL | VALVE, CONTROL |
| 47. | 2436U339F2 | [1] | CONTROL VALVE | KOB |
| 48. | 2436U340F2 | [1] | CONTROL VALVE | KOB |
| 49. | 2418T5974 | [1] | PLATE | |
| 50. | 2418T5975 | [1] | PLATE | |
| 51. | 2432T1163 | [7] | CLAMP | |
| 52. | 2416T6641 | [2] | BRACKET | |
| 53. | 2416T6631 | [2] | BLOCK, TAPPED | |
| 54. | 2416T6632 | [2] | BLOCK, TAPPED | |
| 55. | 24100P751F1 | [1] | CLAMP ASSY CONSISTS OF REF. 55-1 TO 55-6 | CLAMP ASSY CONSISTS OF REF. 55-1 TO 55-6 |
| 55-1. | 2416P5360 | [1] | BRACKET | |
| 55-2. | 2432R109D11 | [2] | CLAMP | |
| 55-3. | 2405Z109D11 | [1] | BUSHING | |
| 55-4. | ZS11C10100 | [2] | CAPSCREW | |
| 55-5. | ZN11C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 55-6. | ZW22X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
