| . . | 24100X625F3 | [1] | INSTAL, LOW, CONSISTS OF ITEM 7 TO 102 | |
| 7. | NSS | [4] | NOT SOLD SEPARAT | CONROLLER ASSY(SEE.P.605) |
| 9. | NSS | [2] | NOT SOLD SEPARAT | CONCYLINDER ASSY,(SEE.P.607) |
| 10. | 2404J116 | [2] | SPROCKET | KOB |
| 13. | 2436U356F1 | [2] | BRAKE VALVE | KOB |
| 14. | 2438U376F1 | [2] | CYLINDER | KOB |
| 16. | 2418N1123 | [2] | | |
| 17. | 2423U126 | [1] | | |
| 17. | 2425U126 | [1] | RING, SLEWING | RING, SLEWING |
| 18. | 2416P3699 | [2] | | |
| 19. | ZP45X35095 | [4] | | |
| 20. | B19T0091 | [1] | | |
| 21. | ZP15D08045 | [4] | | |
| 22. | ZP15005030 | [1] | | |
| 22. | ZP15D05030 | [1] | BASE PLATE Pin, Cotter | BASE PLATE Pin, Cotter |
| 23. | B0610014 | [1] | | |
| 23. | B06T0014 | [1] | LINK | |
| 28. | 2414T949 | [4] | | |
| 29. | 2416T4659 | [4] | | |
| 32. | 2429P318 | [4] | | |
| 33. | 2420T2973 | [2] | ROD | ROD |
| 34. | 2414P1352 | [4] | | |
| 36. | ZS13C24080 | [32] | SCREW | KOBM24x3.0x80mm |
| 37. | ZS13C24090 | [16] | SCREW | KOB |
| 38. | ZS13C24120 | [56] | SCREW | KOBM24x3.0x120mm |
| 39. | ZS23C24130 | [36] | CAPSCREW M24x3.0x130mm | CAPSCREW M24x3.0x130mm |
| 41. | ZS12C16030 | [20] | SCREW,Hex, M16 x 30mm | KOBM16x2.0x30mm |
| 42. | ZS13C16035 | [8] | SCREW | KOBM16x2.0x35mm |
| 43. | ZS23C16045 | [64] | CAP,Hex Socket Head, M16 x 45mm | KOBScrew -- M16x2.0x45mm |
| 44. | ZS23C16070 | [64] | SCREW,Hex Socket Head, M16 x 70mm | KOBM16x2.0x70mm |
| 45. | ZS23C16150 | [16] | | |
| 46. | ZS23C12120 | [4] | SCREW,Hex Socket Head, M12 x 120mm | KOBM12x1.75x120mm |
| 47. | ZS12C12020 | [16] | SCREW,Hex, M12 x 20mm | KOBM12x1.75x20mm Superseded by part number: ZS18C12020 |
| 49. | ZN11C12010 | [2] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 50. | R16T015204 | [68] | | |
| 50. | R16T0152D4 | [68] | WASHER | KOBFlat -- ID 24 x OD 44 x Th 4.5mm |
| 51. | ZW11X16000 | [1] | WASHER | KOBID 16 x OD 30 x Th 2.3mm |
| 52. | ZW11X10000 | [8] | WASHER | KOBID 10 x OD 21 x Th 2.0mm Superseded by part number: ZW16X10000 |
| 53. | ZW11X12000 | [1] | WASHER | KOBID 12 x OD 24 x Th 2.3mm Superseded by part number: ZW16X12000 |
| 54. | ZW22X10000 | [8] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 57. | ZS13C20190 | [8] | | |
| 58. | ZW22K12000 | [4] | LOCK WASHER | KOBID 12.2 x OD 17.8 x Th 2.5mm |
| 59. | ZW22X12000 | [16] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 63. | 2417Z181 | [60] | SPRING | KOB |
| 64. | 2444Z1779 | [4] | ADAPTER | ADAPTER |
| 66. | ZD12G05000 | [4] | O-RING,49.40mm ID x 55.60mm OD x 3.10mm | KOBID 49.40 ± 0.45 x OD 55mm |
| 67. | ZW11X16000 | [8] | WASHER | KOBID 16 x OD 30 x Th 2.3mm |
| 68. | 2419T2365D1 | [2] | | |
| 69. | 2419T2365D2 | [2] | | |
| 70. | 2420T3443 | [20] | SCREW | KOB |
| 71. | 2420T3144 | [20] | | |
| 71. | 2420T3444 | [20] | CAPSCREW | CAPSCREW |
| 72. | 2416T6213 | [20] | BRACKET | BRACKET |
| 73. | 2418P5238 | [12] | PLATE | KOB |
| 74. | 2418P5239 | [8] | PLATE | KOB |
| 77. | NSS | [8] | NOT SOLD SEPARAT | CONROLLER ASSY (SEE.P.603) |
| 78. | NSS | [6] | NOT SOLD SEPARAT | CONROLLER ASSY (SEE.P.604) |
| 79. | 2418P6550 | [2] | | |
| 80. | 2422J922D1 | [1] | | |
| 82. | 2441U285F1 | [2] | MOTOR | MOTOR |
| 83. | NSS | [2] | NOT SOLD SEPARAT | CONREDUCTION UNIT (SEE.P.608) |
| 84. | ZD12P03800 | [4] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 85. | ZS23C14120 | [12] | SCREW,Hex Socket Head, M14 x 120mm | KOBM14x2.0x120mm Superseded by part number: ZS28C14120 |
| 86. | ZW22K14000 | [12] | LOCK WASHER | KOBID 14.2 x OD 21.8 x Th 3.5mm |
| 87. | NSS | [2] | NOT SOLD SEPARAT | CONSPRING ASSY, TRACK (SEE.P.606) |
| 88. | NSS | [2] | NOT SOLD SEPARAT | CONIDLER ASSY (SEE.P.602) |
| 89. | 2436U259F2 | [1] | | |
| 91. | 2418T6689 | [6] | | |
| 92. | ZS12C16055 | [6] | SCREW,Hex, M16 x 55mm | KOBM16x2.0x55mm |
| 95. | 2414T1426 | [4] | | |
| 96. | ZS12C10018 | [8] | | |
| 97. | 2422X466 | [1] | | |
| 98. | 2422J100701 | [1] | | |
| 98. | 2422J1007D1 | [1] | FRAME, CRAWLER | |
| 99. | 2422J1007D2 | [1] | | |
| 100. | 2418T7205 | [20] | SPACER | SPACER |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER ASSY(SEE.P.609) |
| 102. | ZS13C24100 | [36] | SCREW | KOB |
