凯斯零件查询(LBX331S) - BIG RECTANGULAR BALER (6/01-12/03) (05.03[01]) - SINGLE AXLE WITH BRAKES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
664 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84807489
|
[1] |
AXLE
|
ZED
, Serial Range: (2-35)
|
| 1. |
84807490
|
[1] |
AXLE
|
ZED
(2 to 25, Serial Range: 33-36)
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Shaft
|
| 3. |
84807624
|
[2] |
SEAL
|
ZED
Superseded by part number: 84521823
|
| 4. |
84100482
|
[2] |
RING
|
ZED
|
| 5. |
84100483
|
[2] |
BALL BEARING,75mm ID x 130mm OD x 33.25mm W
|
ZED
Superseded by part number: 26800210
|
| 6. |
84100484
|
[2] |
RING
|
ZED
|
| 7. |
84100485
|
[2] |
BALL BEARING,60mm ID x 110mm OD x 29.75mm W
|
ZED
Superseded by part number: 87622924
|
| 8. |
84100486
|
[2] |
NUT
|
ZED
|
| 9. |
84041875
|
[2] |
PIN
|
ZED
|
| 10. |
84100487
|
[2] |
KIT
|
ZED
|
| 11. |
84014229
|
[16] |
BOLT
|
ZED
Superseded by part number: 87472615
|
| 12. |
84045545
|
[16] |
WHEEL NUT
|
ZED
Superseded by part number: 84288019
|
| 13. |
84014230
|
[2] |
PIN
|
ZED
|
| 14. |
80412106
|
[2] |
SLOTTED NUT
|
ZED
Superseded by part number: 412106
|
| 15. |
80412685
|
[4] |
COTTER PIN
|
ZED
Superseded by part number: 412685
|
| 16. |
84014235
|
[4] |
SLEEVE
|
ZED
|
| 17. |
84100490
|
[2] |
SHAFT
|
ZED
Superseded by part number: 84819548
|
| 18. |
80300632
|
[2] |
RETAINER
|
ZED
Superseded by part number: 11068676
|
| 19. |
84014232
|
[4] |
TENSION SPRING
|
ZED
|
| 20. |
84014231
|
[4] |
BRAKE SHOE
|
ZED
|
| 21. |
84043371
|
[2] |
DRUM
|
ZED
|
| 22. |
80140069
|
[2] |
WASHER
|
ZED
Superseded by part number: 140069
|
| 23. |
84014238
|
[2] |
LEVER
|
ZED
|
| 23. |
84807628
|
[2] |
LEVER
|
ZED
LH
|
| 23. |
84807627
|
[2] |
LEVER
|
ZED
RH
|
| 24. |
80726059
|
[2] |
WASHER
|
ZED
Superseded by part number: 84814994
|
| 25. |
80370002
|
[2] |
CIRCLIP
|
ZED
Superseded by part number: 370002
|
| 26. |
80140047
|
[4] |
LOCK WASHER
|
ZED
|
| 27. |
86509597
|
[4] |
BOLT,Hex, M30 x 14mm, Cl 8.8
|
NH
|
| 28. |
80100065
|
[4] |
NUT
|
ZED
|
| 29. |
84100491
|
[2] |
SUPPORT
|
ZED
|
| 30. |
84014243
|
[1] |
CYLINDER
|
ZED
D=30MM
|
| 31. |
84014241
|
[2] |
SPRING
|
ZED
|
| 32. |
84014244
|
[1] |
PIN
|
ZED
|
| 33. |
84053856
|
[1] |
LEVER
|
ZED
|
| 34. |
84045542
|
[1] |
PIN
|
ZED
|
| 35. |
84100480
|
[2] |
HUB
|
ZED
Superseded by part number: 87354761
|
| 36. |
84100493
|
[1] |
SUPPORT
|
ZED
|
