神钢零件查询(K935) - EXCAVATOR BTW L70106 - L70166, LU0067 (1/76-12/03) (08-024) - HYDR LINES, LOW, P/N 24100X626F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
115 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X626F1 | [1] | HYDR LINES ASSY, LOW, CONSISTS OF ITEM 1 TO 48 | |
| 1. | 2418P3713D1 | [2] | TUBE | TUBE |
| 2. | 2418P3713D2 | [2] | TUBE | TUBE |
| 3. | 2418P3714D1 | [2] | TUBE | TUBE |
| 4. | 2418P3714D2 | [2] | TUBE | TUBE |
| 5. | 2418P3804 | [2] | TUBE | |
| 6. | 2418T5016 | [2] | TUBE | |
| 7. | 2418T4997 | [1] | TUBE | |
| 8. | 2418T4998 | [1] | TUBE | |
| 9. | 2444R550D1 | [4] | HOSE (O-2444R650D1) | HOSE (O-2444R650D1) |
| 10. | ZX51M08300 | [2] | HOSE | KOB |
| 11. | ZX53M04300 | [2] | HOSE | KOB |
| 15. | ZE13X16000 | [8] | FLANGE | KOBClamp, Half -- (Incls. Capscrew & Lockwasher) |
| 15. | ZF23E10004 | [2] | HYD CONNECTOR | KOB |
| 16. | ZF33E10004 | [4] | ELBOW | ELBOW |
| 17. | ZF33B35000 | [4] | HYD CONNECTOR | KOB |
| 18. | ZG22E04000 | [1] | HYD CONNECTOR | KOB |
| 19. | 2444T1371 | [1] | CONNECTOR | CONNECTOR |
| 20. | ZG52U04000 | [1] | TEE | KOB |
| 21. | ZG52U08000 | [1] | TEE | KOB |
| 22. | ZH22Z04000 | [2] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 23. | ZH22Z08000 | [2] | HYD CONNECTOR | KOB1/2"PTx1/2"PFx48mm Long |
| 24. | ZH32Z08000 | [2] | ELBOW | KOB |
| 25. | ZF53E10004 | [2] | TEE | TEE |
| 26. | ZC37X10112 | [4] | CLAMP | KOB |
| 27. | ZC37X35114 | [4] | CLAMP | KOB |
| 28. | R16P0036D7 | [2] | CLAMP | KOB Superseded by part number: ZC46X22011 |
| 29. | R16P0036D16 | [2] | CLAMP | |
| 30. | ZD12P03400 | [4] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 31. | ZD12P03800 | [4] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 32. | ZS12C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm Superseded by part number: ZS18C10035 |
| 33. | ZS12C12100 | [2] | SCREW,Hex, M12 x 100mm | KOBM12x1.75x100mm Superseded by part number: ZS18C12100 |
| 31. | ZS23C12040 | [16] | SCREW,Hex Socket Head, M12 x 40mm | KOBM12x1.75x40mm |
| 35. | ZN12C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 36. | ZW22X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 37. | ZW22X12000 | [2] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 38. | ZW22K12000 | [16] | LOCK WASHER | KOBID 12.2 x OD 17.8 x Th 2.5mm |
| 39. | ZW11X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm Superseded by part number: ZW16X10000 |
| 40. | ZS23C14045 | [16] | SCREW,Hex Socket Head, M14 x 45mm | KOBM14x2.0x45mm Superseded by part number: ZS28C14045 |
| 41. | ZW22K14000 | [16] | LOCK WASHER | KOBID 14.2 x OD 21.8 x Th 3.5mm |
| 42. | 2432Z186D1 | [8] | CLIP | CLIP |
| 43. | 2432Z187 | [8] | RING, CLIP | RING, CLIP |
| 48. | ZE13X20001 | [8] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) Superseded by part number: ZE13X20000 |
