凯斯零件查询(LBX331S) - BIG RECTANGULAR BALER (6/01-12/03) (06.01[01]) - ELECTRIC WIRING Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
643 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84437946
|
[1] |
ECU
|
ZED
(2 to 5, fig 06.01A), Serial Range: -C249 Superseded by part number: 84441223
|
| 1. |
84441223
|
[1] |
ECU
|
ZED
(2 to 5, fig 06.01A), Start Serial: D250
|
| 2. |
84429194
|
[1] |
ECU
|
ZED
, Serial Range: -C249 Superseded by part number: 84437943
|
| 2. |
84437943
|
[1] |
ECU
|
ZED
, Start Serial: D250
|
| 3. |
84429195
|
[1] |
SEAL
|
ZED
|
| 4. |
84072075
|
[1] |
SUPPORT
|
ZED
Superseded by part number: 84433364
|
| 5. |
80393802
|
[4] |
SHOCK ABSORBER
|
ZED
Superseded by part number: 393802
|
| 6. |
84400159
|
[1] |
PROTECTING COVER
|
ZED
|
| 7. |
84100277
|
[1] |
DUST CAP
|
ZED
, Serial Range: -C257
|
| 7. |
84441183
|
[1] |
DUST CAP
|
ZED
, Start Serial: D258
|
| 9. |
84433008
|
[1] |
WIRE HARNESS
|
ZED
, Serial Range: -C257
|
| 9. |
84441049
|
[1] |
WIRE HARNESS
|
ZED
, Start Serial: D258
|
| 9. |
84433009
|
[1] |
WIRE HARNESS
|
ZED
, Serial Range: -C257
|
| 9. |
84441048
|
[1] |
WIRE HARNESS
|
ZED
, Start Serial: D258
|
| 10. |
84439335
|
[1] |
WIRE HARNESS
|
ZED
, Serial Range: -C257
|
| 10. |
84440838
|
[1] |
WIRE HARNESS
|
ZED
, Start Serial: D258
|
| 11. |
84078760
|
[1] |
SENSOR
|
ZED
M12, Misstie Sensor
|
| 12. |
84058863
|
[6] |
SENSOR
|
ZED
M18, Motion Sensor
|
| 13. |
86523197
|
[1] |
SENSOR
|
ZED
(14)
|
| 14. |
84320139
|
[1] |
O-RING,2.2mm Thk x 11.3mm ID
|
ZED
|
