纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR ASN YT06-18001 (02-012[01]) - HYDRAULIC LINES, LOWER (DOZER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
474 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT02H00036F1 | [1] | Lower, Dozer | |
| 1. | YT02H01232D1 | [1] | FLEXIBLE HOSE | KOB |
| 2. | YT02H01232D2 | [3] | FLEXIBLE HOSE | KOB |
| 3. | ZX23M04135 | [1] | HOSE | KOB |
| 4. | ZX22M06135 | [1] | HOSE ASSY. | KOB |
| 5. | ZX23M04130 | [1] | HOSE | KOBAssy. |
| 6. | ZX22M06130 | [1] | HOSE | KOBAssy. |
| 7. | ZX56N08084 | [1] | FLEXIBLE HOSE | KOBAssy. |
| 8. | ZX56N08062 | [1] | FLEXIBLE HOSE | KOBAssy. |
| 9. | YT02H01237P1 | [1] | TUBE | KOB |
| 10. | YT02H01238P1 | [1] | TUBE | KOB |
| 11. | YT02H01243P1 | [2] | GROMMET | KOB |
| 12. | YT02H01234P1 | [2] | GROMMET | KOB |
| 13. | ZC26X15009 | [2] | CLAMP | KOB |
| 14. | ZW26X08000 | [2] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| 15. | ZS18C08040 | [2] | SCREW,Hex, M8 x 40mm | KOBCap |
| 16. | PY01P01043D8 | [6] | CABLE TIE,102mm L | KOB |
