现代零件查询R500LC-7 FUEL SYSTEM(#0632-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
630 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
FUEL SYSTEM
|
|
| 1. |
11NB-70400
|
[1] |
PREFILTER ASSY
|
|
| 1. |
11LB-20300
|
[1] |
PREFILTER ASSY
|
|
| 1-1. |
11LD-20240
|
[1] |
HEAD-FILTER
|
|
| 1-2. |
11LB-20310
|
[1] |
ELEMENT ASSY-F/FILTER
|
|
| 1-3. |
11NB-70410
|
[1] |
BOWL ASSY-W/HEATER
|
|
| 1-3. |
11LD-20260
|
[1] |
BOWL ASSY-W/KNOB
|
|
| 2. |
11QB-50070
|
[1] |
HOSE-FUEL
|
|
| 2. |
P460-080037
|
[1] |
HOSE ASSY-FUEL 0X0
|
|
| 3. |
11QB-50050
|
[1] |
HOSE-FUEL
|
|
| 4. |
11QB-50060
|
[1] |
HOSE-FUEL
|
|
| 4. |
11QB-50090
|
[1] |
HOSE-FUEL
|
|
| 5. |
11NB-50020
|
[1] |
HOSE ASSY
|
|
| 6. |
11M8-50030
|
[1] |
HOSE ASSY
|
|
| 7. |
11ND-50060
|
[1] |
ELBOW-90,ORFS
|
|
| 8. |
11Q4-50010
|
[1] |
VALVE-FUEL CUT
|
|
| 9. |
11QB-50040
|
[2] |
CONNECTOR
|
|
| 10. |
P020-110003
|
[2] |
ELBOW-90
|
|
| 11. |
S520-015000
|
[1] |
CLAMP-HOSE,S/DRIVE
|
|
| 12. |
31L7-10200
|
[9] |
CLAMP-TUBE
|
|
| 13. |
S035-082526
|
[2] |
BOLT-W/WASHER
|
|
| 14. |
S037-101526
|
[9] |
BOLT-W/WASHER
|
|
| 15. |
11NA-70410
|
[1] |
FUEL WARMER KIT
|
|
| 15-1. |
392702300
|
[1] |
HEATER
|
|
| 15-2. |
392666000
|
[1] |
O-RING
|
|
| 15-3. |
393430000
|
[1] |
INSERT
|
|
| 15-4. |
393446900
|
[1] |
ADAPTER
|
|
| 15-5. |
391902500
|
[1] |
GASKET
|
|
| 15-6. |
@
|
[1] |
GLUE
|
|
| 16. |
11N8-50070
|
[1] |
PLUG
|
|
| 17. |
31L7-10340
|
[1] |
CLAMP-TUBE INS
|
|
