| . . | 24100J1950F1 | [1] | ARM ASSY, CONSISTS OF REF 1 TO 59 | |
| 1. | 2411J930F1 | [1] | ARM, CONSISTS OF REF 1-2 & 1-3 | |
| 1-2. | 2405T702 | [4] | BUSHING | KOB |
| 1-3. | 2405T703 | [2] | BUSHING | KOB |
| 2. | 2406J114F1 | [2] | LINK | KOBCONSISTS OF REF 2-2 & 2-3 |
| 2-2. | 2405T700 | [1] | BUSHING | BUSHING |
| 2-3. | 2405T701 | [1] | BUSHING | BUSHING |
| 3. | 2406J115F1 | [1] | LINK, BUCKET | |
| 3-2. | 2405T698 | [2] | BUSHING CONSISTS OF REF 3-2 TO 3-4 | BUSHING CONSISTS OF REF 3-2 TO 3-4 |
| 3-3. | 2405T699 | [2] | BUSHING | |
| 3-4. | 44Z1D10 | [2] | FITTING | KOB |
| 4. | 2438U469F1 | [1] | CYLINDER | |
| 5. | 2419P944 | [1] | PIN | |
| 6. | 2419P946 | [2] | PIN | PIN |
| 7. | 2419P945 | [1] | PIN | PIN |
| 8. | 2419P943 | [2] | PIN | |
| 9. | 2418P4454 | [1] | TUBE | KOB |
| 10. | 2418T5558 | [1] | TUBE | TUBE |
| 11. | 2432T781 | [2] | CLAMP | CLAMP |
| 12. | 2432T995 | [6] | CLAMP | KOB |
| 13. | R16P0035D3 | [2] | CLAMP | KOB |
| 14. | B16T0006 | [2] | PLATE | PLATE |
| 15. | R16T0030 | [2] | BLOCK, TRAPPED | |
| 16. | R16P0036D17 | [3] | CLAMP | CLAMP |
| 17. | 2444R488D6 | [2] | HOSE | HOSE |
| 18. | 2420R349D9 | [1] | HOSE ASSY | HOSE ASSY |
| 19. | 2420R349D13 | [1] | HOSE | HOSE |
| 20. | ZX55M04100 | [4] | HOSE | |
| 21. | 2420R349D7 | [2] | HOSE | KOBHOSE Superseded by part number: 2420R349D200 |
| 22. | R44P0034 | [2] | CONNECTOR | CONNECTOR |
| 23. | ZH32Z04000 | [5] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 24. | ZH22Z04000 | [7] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 25. | 2418T5225D1 | [1] | | |
| 26. | 2418T5225D2 | [1] | | |
| 27. | 2418T5225D3 | [1] | SHIM, 2.3 | |
| 28. | 2418T5225D4 | [1] | SHIM, 3.2 | |
| 29. | 2420T2747D7 | [1] | SHIM,112mm ID x 180mm OD x 1.2mm Thk | KOBID 112 x OD 180 x Th 1.2mm |
| 30. | 2420T2747D8 | [1] | SHIM,112mm ID x 180mm OD x 1.6mm Thk | KOBID 112 x OD 180 x Th 1.6mm |
| 31. | 2420T2747D9 | [1] | SHIM,112mm ID x 180mm OD x 2.3mm Thk | KOBID 112 x OD 180 x Th 2.3mm |
| 32. | 2420T2747D10 | [1] | SHIM,112mm ID x 180mm OD x 3.2mm Thk | KOBID 112 x OD 180 x Th 3.2mm |
| 33. | 2418T5224D1 | [1] | SHIM | KOB |
| 34. | 2418T5224D2 | [1] | SHIM | KOB |
| 35. | 2418T5224D3 | [1] | SHIM | KOB |
| 36. | 2418T5224D4 | [1] | SHIM | KOB |
| 37. | 2420T2747D2 | [1] | SHIM,102mm ID x 170mm OD x 1.2mm Thk | KOBID 102 x OD 170 x Th 1.2mm |
| 38. | 2420T2747D3 | [1] | SHIM,102mm ID x 170mm OD x 1.6mm Thk | KOBID 102 x OD 170 x Th 1.6mm |
| 39. | 2420T2747D4 | [1] | SHIM,102mm ID x 170mm OD x 2.3mm Thk | KOBID 102 x OD 170 x Th 2.3mm |
| 40. | 2420T2747D5 | [1] | SHIM,102mm ID x 170mm OD x 3.2mm Thk | KOBID 102 x OD 170 x Th 3.2mm |
| 41. | ZS11C12130 | [4] | CAPSCREW | |
| 42. | ZS11C12120 | [12] | CAPSCREW M12x1.75x120mm | CAPSCREW M12x1.75x120mm |
| 43. | ZS12C16080 | [4] | CAPSCREW M16x2.0x80mm | CAPSCREW M16x2.0x80mm |
| 44. | ZS12C12030 | [4] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm Superseded by part number: ZS18C12030 |
| 45. | ZS12C08012 | [3] | CAPSCREW M08x1.25x12mm | CAPSCREW M08x1.25x12mm |
| 46. | R20T0033D3 | [4] | CAPSCREW | |
| 47. | ZN11C12010 | [32] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 48. | R20T0033D1 | [4] | CAPSCREW | |
| 49. | ZW22X16000 | [4] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 50. | ZW22X12000 | [4] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 51. | ZW22X08000 | [3] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 52. | ZW22X14000 | [8] | LOCK WASHER | KOBID 14 x OD 24.5 x Th 3.5mm Superseded by part number: ZW26X14000 |
| 53. | ZD12P03800 | [2] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 54. | 44Z1D10 | [8] | FITTING | KOB |
| 55. | ZN12C16013 | [4] | NUT | KOBM16x2.0mm |
| 56. | R16T0227D3 | [2] | SPACER | KOB |
| 57. | 2418T5364 | [2] | SPACER | KOB |
| 59. | ZG32B04000 | [4] | ELBOW | KOB |
