神钢零件查询(K935) - EXCAVATOR BTW L70106 - L70166, LU0067 (1/76-12/03) (09-027) - BEARING Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
683 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2425U126 | [1] | RING, SLEWING (BEARING), CONSISTS OF ITEM 1 TO 8 | RING, SLEWING (BEARING), CONSISTS OF ITEM 1 TO 8 |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONRACE, OUTER |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONRACE, INNER |
| 3. | NSS | [86] | NOT SOLD SEPARAT | CONBALL |
| 4. | NSS | [45] | NOT SOLD SEPARAT | CONSEPARATOR, RUBBER |
| 5. | NSS | [45] | NOT SOLD SEPARAT | CONSEPARATOR, METAL |
| 6. | 24025Z9D2 | [1] | SEAL, DUST | SEAL, DUST |
| 7. | 24025Z9D2 | [1] | SEAL, DUST | SEAL, DUST |
| 8. | ZG91S02000 | [4] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
