纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR ASN YT06-18001 (01-005[02]) - ENGINE INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
906 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT02P01011P1 | [1] | BRACKET | KOB |
| 2. | YT02P01006P1 | [4] | RUBBER MOUNTING | KOB |
| 3. | YT02P01019P1 | [4] | PLATE | KOB |
| 4. | PW01P01022P1 | [4] | WASHER | KOB |
| 5. | HS18C12120G1 | [4] | CAPTIVE WASHER SCREW | KOB |
| 6. | ZW16H12000 | [6] | WASHER | KOB |
| 7. | ZN18C12010 | [2] | NUT | KOB |
| 8. | ZM73C10030 | [10] | BOLT,M10x30mm - Course Thread | KOBSems |
| 9. | YT02P01015P1 | [2] | HOSE ASSY. | KOB |
| 10. | ZH22X08012 | [2] | HYD CONNECTOR | KOB |
| 11. | YT02P01018P1 | [4] | RUBBER MOUNTING | KOB |
| 12. | HD16P02400G2 | [5] | O-RING | KOB |
| 13. | PY01P01043D2 | [1] | CABLE TIE,4.60mm W x 202mm L | KOB Superseded by part number: YT50C01100P1 |
