凯斯零件查询(LBX331S) - BIG RECTANGULAR BALER (6/01-12/03) (07.02[01]) - HYDRAULIC BRAKES, TANDEM AXLE, NOT FOR NA Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
934 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
89839028
|
[1] |
HYD CONNECTOR
|
ZED
Superseded by part number: 9839028
|
| 2. |
80395019
|
[1] |
HYD CONNECTOR
|
ZED
Superseded by part number: 395019
|
| 3. |
84078363
|
[2] |
FLEXIBLE HOSE
|
ZED
|
| 4. |
89813512
|
[4] |
HYD CONNECTOR
|
ZED
|
| 5. |
89839026
|
[1] |
HOSE
|
ZED
Superseded by part number: 84449978
|
| 6. |
84078124
|
[2] |
HYD CONNECTOR,9/16" - 18 JIC x M16 x 1.5
|
ZED
|
| 7. |
80418284
|
[1] |
ELBOW
|
ZED
Superseded by part number: 418284
|
| 8. |
80395472
|
[3] |
3 WAY CONNECTION
|
ZED
Superseded by part number: 395472
|
| 9. |
80150014
|
[1] |
FERRULE
|
ZED
10MM Superseded by part number: 150014
|
| 10. |
86548975
|
[1] |
PIPE UNION NUT,M16 x 1.5
|
ZED
M10
|
| 11. |
80371539
|
[1] |
RIGID TUBE
|
ZED
D=10mm, L=2m Superseded by part number: 371539
|
| 13. |
84031413
|
[1] |
HYDRAULIC HOSE,7.9mm ID x 2500mm L, SAE 100R1
|
ZED
|
| 14. |
84007700
|
[1] |
ELBOW
|
ZED
|
| 15. |
80150017
|
[2] |
HYD CONNECTOR
|
ZED
Superseded by part number: 47499003
|
| 18. |
NS
|
[1] |
NOT SERVICED
|
BAS
Tube
|
| 19. |
80323597
|
[2] |
STRAP
|
ZED
Superseded by part number: 14560287
|
