纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR ASN YT06-18001 (01-016[01]) - SWING MOTOR INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
928 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT32W00003F1 | [1] | Swing | |
| 1. | ZS13C16050 | [8] | SCREW | KOBCap |
| 2. | ZW13H16000 | [8] | WASHER | KOB |
| 3. | YT32W01003D1 | [1] | PIPE | KOB |
| 4. | ZE82T08000 | [1] | PLUG | KOB |
| 5. | ZC46X19011 | [1] | CLIP | KOB |
| 6. | ZM73C10016 | [1] | BOLT,M10x16mm - Course Thread | KOBSems |
| 7. | YT15V00015F1 | [1] | MOTOR | KOBAssy., Hyd. |
| 8. | YT15V00016F1 | [1] | MOTOR | KOBAssy. Superseded by part number: YT15V00005F2 |
| 9. | YT32W00006F1 | [1] | REDUCER | KOBAssy. |
| 10. | 2444R1117D032 | [1] | FLEXIBLE HOSE,6.40mm ID x 320mm L | KOB |
| 11. | YT32W01004P1 | [1] | ELBOW | KOB |
| 12. | 2444Z2002 | [1] | HYD CONNECTOR | KOB |
| 13. | ZG22E02000 | [1] | HYD CONNECTOR | KOB |
| 14. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB |
