纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR ASN YT06-18001 (01-021[01]) - HYDRAULIC LINES, UPPER (NIBBLER & BREAKER + DOZER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
551 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT03H00125F1 | [1] | Upp., Nibbler & Breaker + Dozer | |
| 1. | YT03H00142F1 | [1] | Upp. | |
| 2. | YT03H01169D5 | [1] | HOSE ASSY. | KOB |
| 3. | YT03H01025DC | [1] | HOSE ASSY. | KOB |
| 4. | YT03H01025D3 | [4] | FLEXIBLE HOSE | KOB |
| 5. | YT03H01026DN | [1] | HOSE ASSY. | KOB |
| 6. | YT03H01142D1 | [1] | FLEXIBLE HOSE | KOB |
| 7. | YT03H01169D1 | [1] | HOSE ASSY. | KOB |
| 8. | YT03H01025DB | [1] | HOSE ASSY. | KOB |
| 9. | YR03H01066P2 | [2] | ELBOW | KOB |
| 10. | YT03H01124P1 | [2] | BLOCK | KOB |
| 11. | YT03H01140P1 | [1] | BRACKET | KOB |
| 12. | YT03H01108P1 | [1] | GUIDE | KOB |
| 13. | YT03H01127P1 | [2] | BUSHING | KOB |
| 14. | YN64H01018P1 | [1] | GROMMET | KOB |
| 15. | 2420Z2185 | [1] | GROMMET | KOB |
| 16. | YT03H01123P1 | [1] | CLAMP | KOB |
| 17. | ZM73C12025 | [1] | BOLT,M12x25mm - Course Thread | KOBSems |
| 18. | ZM73C12030 | [3] | BOLT,M12x30mm - Course Thread | KOBSems |
| 19. | ZS18C10090 | [4] | SCREW,Hex, M10 x 90mm | KOBCap |
| 20. | ZW16H10000 | [4] | WASHER | KOB |
| 21. | PY01P01043D3 | [2] | CABLE TIE,188mm L | KOB |
| 22. | PY01P01043D8 | [7] | CABLE TIE,102mm L | KOB |
| 23. | YT03H01170D3 | [1] | HOSE ASSY. | KOB |
| 24. | YT03H01170D4 | [1] | HOSE ASSY. | KOB |
