久保田零件查询T02100 DYNAMO GROUP ENGINEEPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
235 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 001. |
1537264040
|
[1] |
ROTOR
|
2.0900(lbs); 0.950
|
| 002. |
1537264290
|
[1] |
ASSY STATOR
|
0.5060(lbs); 0.230
|
| 003. |
1526193010
|
[3] |
SCREW
|
0.0066(lbs); 0.003
|
| 004. |
1537264360
|
[1] |
BASE STAR STATOR
|
0.0000(lbs); 0.000
|
| 005. |
0812306201
|
[2] |
BEARING BALL
|
0.0000(lbs); 0.000
|
| 006. |
1526164150
|
[1] |
COLLAR
|
0.0440(lbs); 0.020
|
| 007. |
1526195470
|
[1] |
CIR-CLIP INTERNAL
|
0.0044(lbs); 0.002
|
| 008. |
1537274140
|
[1] |
SHAFT FAN
|
0.4840(lbs); 0.220
|
| 009. |
1526194020
|
[1] |
WASHER PLAIN
|
0.0154(lbs); 0.007
|
| 010. |
1526194070
|
[1] |
WASHER SPRING
|
0.0066(lbs); 0.003
|
| 011. |
1526192030
|
[1] |
NUT
|
0.0220(lbs); 0.010
|
| 012. |
1524164370
|
[3] |
SHIM
|
0.0022(lbs); 0.001
|
| 013. |
1526164140
|
[1] |
COLLAR
|
0.0550(lbs); 0.025
|
