凯斯零件查询(LBX331S) - BIG RECTANGULAR BALER (6/01-12/03) (13.31[01]) - SHUTTLE FEEDER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
366 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84078652
|
[1] |
ARM
|
ZED
LH
|
| 2. |
84078650
|
[1] |
ARM
|
ZED
RH
|
| 3. |
84078654
|
[2] |
ROLLER
|
ZED
, Serial Range: (4-7)
|
| 4. |
9838669
|
[2] |
LUBE NIPPLE
|
ZED
Superseded by part number: 84062065
|
| 5. |
NSS
|
[2] |
NOT SOLD SEPARAT
|
CON
Bolt
|
| 6. |
89850911
|
[2] |
RING
|
ZED
Superseded by part number: 9850911
|
| 7. |
89839123
|
[2] |
BEARING ASSY
|
ZED
Superseded by part number: 9839123
|
| 8. |
89838834
|
[4] |
SHIM
|
ZED
Superseded by part number: 9838834
|
| 9. |
89837743
|
[6] |
WASHER
|
ZED
Superseded by part number: 9837743
|
| 10. |
84000258
|
[4] |
BUSHING,55mm ID x 60mm OD x 40mm L
|
ZED
|
| 11. |
80300389
|
[4] |
BOLT,M12 x 35mm
|
ZED
M12x35 Superseded by part number: 628-12035
|
| 12. |
80394630
|
[8] |
WASHER
|
ZED
12MM Superseded by part number: 86625256
|
| 13. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 14. |
84807173
|
[2] |
SPRING
|
ZED
|
| 15. |
80330413
|
[2] |
BANJO BOLT
|
ZED
Superseded by part number: 330413
|
| 16. |
89706687
|
[2] |
SCREW
|
ZED
M12x30 Superseded by part number: 9706687
|
| 17. |
89801096
|
[2] |
WASHER
|
ZED
Superseded by part number: 9801096
|
| 18. |
84807395
|
[2] |
BRACKET
|
ZED
|
| 19. |
84015202
|
[2] |
BALL BEARING,25mm ID x 62mm OD x 20.6mm W
|
ZED
|
| 20. |
80370002
|
[2] |
CIRCLIP
|
ZED
Superseded by part number: 370002
|
| 21. |
80140096
|
[1] |
WASHER
|
ZED
Superseded by part number: 9820493
|
| 22. |
80443434
|
[1] |
WASHER
|
ZED
Superseded by part number: 443434
|
| 23. |
80322359
|
[2] |
LOCK WASHER
|
ZED
20MM Superseded by part number: 322359
|
| 24. |
80320771
|
[2] |
NUT
|
ZED
M20x1.5 Superseded by part number: 320771
|
| 25. |
84032523
|
[1] |
WASHER
|
ZED
M10
|
| 26. |
80140045
|
[2] |
WASHER
|
ZED
10MM Superseded by part number: 140045
|
| 27. |
80190029
|
[2] |
RUBBER BUMPER
|
ZED
Superseded by part number: 84440416
|
| 28. |
84817553
|
[1] |
WASHER
|
ZED
|
