| 1. |
832-46416
|
[2] |
NUT,M16 x 2, Cl 8
|
CAS
Superseded by part number: 86000441
|
| 2. |
80378246
|
[5] |
WASHER
|
ZED
Superseded by part number: 378246
|
| 3. |
84031600
|
[1] |
DRIVEN SPROCKET
|
ZED
|
| 4. |
120104
|
[8] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 5. |
80322358
|
[17] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 7. |
84031598
|
[1] |
IDLER WHEEL
|
ZED
|
| 8. |
80431485
|
[2] |
UNIVERSAL JOINT
|
ZED
Superseded by part number: 431485
|
| 9. |
84031596
|
[1] |
EXTENSION
|
ZED
|
| 9. |
84031594
|
[1] |
EXTENSION
|
ZED
|
| 10. |
43128
|
[8] |
BOLT,M8 x 1.25 x 30mm, Cl 8.8
|
NH
|
| 11. |
84031592
|
[1] |
SHAFT
|
ZED
|
| 12. |
80140016
|
[8] |
WASHER
|
ZED
8MM Superseded by part number: 86624184
|
| 12. |
80130003
|
[1] |
COTTER PIN
|
ZED
Superseded by part number: 130003
|
| 13. |
84074878
|
[1] |
SUPPORT
|
ZED
|
| 14. |
89706685
|
[2] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 15. |
80140046
|
[2] |
WASHER
|
ZED
12MM Superseded by part number: 140046
|
| 16. |
89838302
|
[2] |
WASHER
|
ZED
Superseded by part number: 9838302
|
| 17. |
80395589
|
[2] |
SLEEVE
|
ZED
Superseded by part number: 395589
|
| 18. |
80328754
|
[3] |
SCREW
|
ZED
M12x35 Superseded by part number: 328754
|
| 19. |
84021291
|
[2] |
DISC
|
ZED
|
| 20. |
89838303
|
[1] |
GEAR
|
ZED
Superseded by part number: 9838303
|
| 21. |
80647695
|
[1] |
PIN
|
ZED
Superseded by part number: 647695
|
| 22. |
84031241
|
[1] |
SUPPORT
|
ZED
|
| 23. |
84058905
|
[1] |
SECTOR
|
ZED
TOOTHED SECTOR
|
| 24. |
84031235
|
[1] |
PLATE
|
ZED
|
| 25. |
89838309
|
[1] |
LEVER
|
ZED
Superseded by part number: 9838309
|
| 26. |
89838305
|
[2] |
WASHER
|
ZED
Superseded by part number: 9838305
|
| 27. |
80370002
|
[1] |
CIRCLIP
|
ZED
Superseded by part number: 370002
|
| 28. |
80323787
|
[1] |
LUBE NIPPLE
|
ZED
Superseded by part number: N13505
|
| 29. |
84607524
|
[1] |
BUSHING,10.5mm ID x 16mm OD x 17.5mm L
|
ZED
|
| 30. |
89706704
|
[1] |
BOLT,M10 x 35mm
|
ZED
M10x35 Superseded by part number: 9706704
|
| 31. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 32. |
89838295
|
[1] |
BOLT
|
ZED
Superseded by part number: 9838295
|
| 33. |
89838278
|
[1] |
SPRING
|
ZED
Superseded by part number: 9838278
|
| 34. |
80338949
|
[2] |
CARRIAGE BOLT
|
ZED
M10x25 Superseded by part number: 338949
|
| 35. |
80140045
|
[1] |
WASHER
|
ZED
10MM Superseded by part number: 140045
|
| 36. |
84014935
|
[1] |
THREADED TIE-ROD
|
ZED
|
| 37. |
89838296
|
[1] |
HANDLE
|
ZED
Superseded by part number: 9838296
|
| 38. |
89838297
|
[1] |
CLEVIS
|
ZED
Superseded by part number: 9838297
|
| 39. |
80323238
|
[1] |
NUT
|
ZED
M12 Superseded by part number: 323238
|
| 40. |
89838300
|
[1] |
ROD
|
ZED
Superseded by part number: 9838300
|
| 41. |
80378245
|
[2] |
WASHER
|
ZED
12MM Superseded by part number: 378245
|
| 42. |
80130005
|
[1] |
COTTER PIN
|
ZED
Superseded by part number: 130005
|
| 43. |
80412126
|
[1] |
LOCK NUT
|
ZED
M12 Superseded by part number: 412126
|
| 44. |
89838279
|
[3] |
WASHER
|
ZED
Superseded by part number: 9838279
|
| 45. |
84032061
|
[1] |
PLATE
|
ZED
|
| 46. |
614-6016
|
[2] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86508568
|
| 47. |
80322357
|
[2] |
LOCK WASHER,Belleville, M6
|
ZED
Superseded by part number: 322357
|
| 49. |
89812123
|
[1] |
RING
|
ZED
Superseded by part number: 9812123
|
| 50. |
89838938
|
[1] |
BALE COUNTER
|
ZED
Superseded by part number: 86608973
|
| 51. |
89838937
|
[1] |
SPRING
|
ZED
Superseded by part number: 9838937
|
| 52. |
84032097
|
[1] |
CHAIN
|
ZED
|
| 54. |
84031601
|
[1] |
SHIELD
|
ZED
|
| 55. |
80378244
|
[2] |
LOCK WASHER
|
ZED
10MM Superseded by part number: 378244
|
| 6. |
89706690
|
[17] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 48. |
15896221
|
[2] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
