纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR ASN YT06-18001 (01-050[07]) - CONTROLS, OPERATORS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
392 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT55M00012F1 | [1] | | |
| 2. | YN26M00074P1 | [1] | CARPET | SMFloor |
| 3. | YY55M01009P1 | [1] | PLATE | KOB |
| 4. | ZM73C10020 | [4] | BOLT,M10x20mm - Course Thread | KOBSems |
| 5. | YT55M01057P3 | [1] | PEDAL | KOB |
| 6. | YT55M01060P1 | [1] | PLATE | KOB |
| 7. | YT55M01072F1 | [1] | LOCK | KOBAssy. |
| 8. | YT55M01073P1 | [1] | | |
| 9. | 2405R312D1210 | [2] | BUSHING | KOB |
| 10. | YT55M01052P1 | [1] | BAR | KOB |
| 11. | YT55M01053P1 | [1] | BAR | KOB |
| 12. | ZP26K02512 | [1] | PIN | KOBSpring |
| 13. | ZM73C08020 | [6] | BOLT,M8x20mm - Course Thread | KOBSems |
| 14. | YN03M01858P1 | [1] | RUBBER PEDAL PAD | SM |
