纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR ASN YT06-18001 (01-054[01]) - CONTROLLER INSTALLATION (ROPS CAB) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
695 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT22E00091F1 | [1] | Rops Cab | |
| 1. | YT22E00090F1 | [1] | ECU | KOB |
| 2. | YT22E01190P1 | [1] | BRACKET, SUPPORTING | KOB, Serial Range: YT06-18001-YT06-18386 |
| 2. | YT22E01190P2 | [1] | , Start Serial: YT06-18387 | |
| 3. | YT22E01195P1 | [1] | BRACKET | KOB |
| 4. | YN50S00047P1 | [1] | TOGGLE SWITCH | KOB |
| 5. | YN22M01014P1 | [1] | LABEL | KOB |
| 6. | ZM61C06016 | [6] | BOLT | KOB |
| 7. | ZM61C06025 | [7] | BOLT | KOB |
| 8. | ZM73C08020 | [4] | BOLT,M8x20mm - Course Thread | KOB |
| 9. | PM22C01020DH | [1] | INSULATING PANEL | KOBTrim |
| 10. | PM22C01020DR | [1] | TRIM PANEL | KOB, Start Serial: YT06-18387 |
| 11. | YT22E00063F4 | [1] | ECU | KOB Superseded by part number: YT22E00063F5 |
