| 1. |
80385681
|
[1] |
LOCK NUT
|
ZED
Superseded by part number: 385681
|
| 2. |
80322355
|
[1] |
WASHER
|
ZED
Superseded by part number: 322355
|
| 3. |
80335872
|
[1] |
WASHER
|
ZED
Superseded by part number: 335872
|
| 4. |
84011441
|
[1] |
RING,6mm ID x 60mm OD x 2mm Thk
|
ZED
|
| 5. |
86511824
|
[1] |
SCREW,Phillips Drive, Pan HD, M4 x 0.7 x 20mm, Cl 4.8
|
NH
|
| 6. |
84019720
|
[1] |
ROD
|
ZED
|
| 8. |
84074558
|
[1] |
SUPPORT
|
ZED
RH
|
| 9. |
84078879
|
[1] |
SUPPORT
|
ZED
|
| 9. |
84078877
|
[1] |
SUPPORT
|
ZED
|
| 10. |
84000177
|
[1] |
SUPPORT
|
ZED
LH
|
| 11. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 12. |
80140045
|
[1] |
WASHER
|
ZED
Superseded by part number: 140045
|
| 13. |
80130004
|
[1] |
COTTER PIN
|
ZED
Superseded by part number: 130004
|
| 14. |
80043117
|
[1] |
SCREW
|
ZED
M6x30 Superseded by part number: 87317695
|
| 15. |
80120041
|
[1] |
CARRIAGE BOLT
|
ZED
Superseded by part number: 120041
|
| 16. |
84806599
|
[1] |
SPRING
|
ZED
Upper
|
| 16. |
84807327
|
[1] |
SPRING
|
ZED
Lower
|
| 17. |
80043130
|
[8] |
SCREW,M8 x 50mm
|
ZED
M8x50 Superseded by part number: 43130
|
| 18. |
84005807
|
[1] |
SUPPORT
|
ZED
Upper
|
| 18. |
84000767
|
[1] |
SUPPORT
|
ZED
Lower Superseded by part number: 87352418
|
| 19. |
84078917
|
[1] |
ARM
|
ZED
|
| 20. |
80043442
|
[1] |
NUT,M8 x 1.25, Cl 8
|
ZED
Superseded by part number: 82034883
|
| 21. |
80322357
|
[1] |
LOCK WASHER,Belleville, M6
|
ZED
6MM Superseded by part number: 322357
|
| 22. |
80353308
|
[1] |
NUT
|
ZED
M6 Superseded by part number: 353308
|
| 23. |
89838236
|
[1] |
ROLLER
|
ZED
Superseded by part number: 47508395
|
| 25. |
80080680
|
[1] |
LOCK WASHER
|
ZED
Superseded by part number: 80680
|
| 26. |
280136
|
[1] |
NUT,3/8"-16, G8
|
WIN
|
| 27. |
84018757
|
[1] |
BOLT,M10 x 1.5 x 160mm, CL 4.6
|
ZED
M10x160
|
| 28. |
80300507
|
[1] |
SCREW
|
ZED
M6x35 Superseded by part number: 86977789
|
| 29. |
80799339
|
[1] |
U-BOLT
|
ZED
Superseded by part number: 799339
|
| 30. |
84429814
|
[1] |
GUIDE BUSHING
|
ZED
|
| 31. |
80412141
|
[1] |
LOCK NUT
|
ZED
M10 Superseded by part number: 190003888452
|
| 32. |
86511323
|
[1] |
WASHER,10.5mm ID x 20mm OD x 2mm Thk
|
NH
Superseded by part number: 14496621
|
| 33. |
89838888
|
[1] |
SPRING
|
ZED
Superseded by part number: 858027
|
| 34. |
80140015
|
[1] |
WASHER
|
ZED
6MM Superseded by part number: 86588450
|
| 35. |
84022924
|
[1] |
STEP BOLT,3/8" - 16 x 2.17"
|
ZED
|
| 36. |
84320035
|
[1] |
SUPPORT
|
ZED
|
| 37. |
89838895
|
[1] |
DRIVEN SPROCKET
|
ZED
Superseded by part number: 9838895
|
| 38. |
89838894
|
[1] |
SPACER
|
ZED
Superseded by part number: 9838894
|
| 39. |
89838902
|
[1] |
SUPPORT
|
ZED
Superseded by part number: 9838902
|
| 40. |
80102043
|
[1] |
GROMMET
|
ZED
Superseded by part number: 102043
|
| 41. |
80412152
|
[1] |
NUT
|
ZED
Superseded by part number: 412152
|
| 42. |
80120102
|
[1] |
SCREW
|
ZED
Superseded by part number: 120102
|
| 43. |
84032625
|
[1] |
SCRAPER BLADE
|
ZED
|
| 44. |
84078867
|
[1] |
FIXING PLATE
|
ZED
|
| 44. |
84078865
|
[1] |
FIXING PLATE
|
ZED
|
| 45. |
84078868
|
[1] |
CANVAS
|
ZED
|
| 45. |
84078869
|
[1] |
CANVAS
|
ZED
|
| 46. |
84078873
|
[1] |
PLATE
|
ZED
|
| 46. |
84078875
|
[1] |
PLATE
|
ZED
|
| 47. |
614-6016
|
[1] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86508568
|
| 7. |
15896221
|
[1] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
