现代零件查询R500LC-7 CYLINDER BLOCK(#0632-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
153 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
4060394
|
[1] |
CYLINDER BLOCK
|
|
| N1. |
3329058
|
[1] |
BLOCK-CYLINDER
|
|
| 2. |
148555
|
[2] |
DOWEL-PIN
|
|
| 3. |
179063
|
[1] |
PLUG-RETAINER
|
|
| 4. |
3014754
|
[1] |
WASHER-PLAIN
|
|
| 5. |
3014755
|
[1] |
DISC-VALVE
|
|
| 6. |
3014756
|
[1] |
SPRING
|
|
| 7. |
2878168
|
[7] |
BUSHING
|
|
| 8. |
3008466
|
[2] |
PLUG-PIPE
|
|
| 9. |
3026758
|
[1] |
SEAT-PRESS R/VLV
|
|
| 10. |
4060388
|
[1] |
CAP-MAIN BEARING
|
|
| 10. |
4060391
|
[1] |
CAP-MAIN BEARING
|
|
| 10. |
3026961
|
[6] |
CAP-MAIN BEARING
|
|
| N -1. |
3803504
|
[14] |
KIT-SCREW HEX CAP
|
|
| 11. |
3019631
|
[1] |
WASHER-PLAIN
|
|
| 12. |
3328742
|
[1] |
SCREW-HEX HEAD CAP
|
|
| 13. |
3895832
|
[7] |
STUD
|
|
| 14. |
70550
|
[1] |
DOWEL-PIN
|
|
| 15. |
142207
|
[2] |
DOWEL-PIN
|
|
| 16. |
3007635
|
[4] |
PLUG-EXPANSION
|
|
| 17. |
3007632
|
[5] |
PLUG-EXPANSION
|
|
| 18. |
3008446
|
[3] |
DOWEL-PIN
|
|
| 19. |
3008468
|
[1] |
PLUG-PIPE
|
|
| 20. |
3026231
|
[3] |
DOWEL-RING
|
|
| -2. |
3037536
|
[4] |
PLUG-THREADED
|
|
| 21. |
3037536
|
[1] |
PLUG-THREADED
|
|
| 22. |
3037537
|
[1] |
O-RING
|
|
| -3. |
3046202
|
[1] |
PLUG-THREADED
|
|
| N23. |
3040810
|
[1] |
PLUG-THREADED
|
|
| 24. |
3046201
|
[1] |
O-RING
|
|
| 25. |
3069728
|
[1] |
SENSOR-VISCOSITY
|
|
| 26. |
3068979
|
[1] |
PLUNGER
|
|
| 27. |
3010146
|
[1] |
SPRING-COMP
|
|
| 28. |
3821725
|
[1] |
PLUG-RETAINER
|
|
| 29. |
3042619
|
[1] |
NIPPLE-COUPLING
|
|
| -4. |
3053349
|
[1] |
PIN-DOWEL
|
|
| -5. |
3803703
|
[6] |
KIT-CYLINDER LINER
|
|
| N41. |
3080760
|
[1] |
LINER-CYLINDER
|
|
| 42. |
3047188
|
[1] |
SEAL-RECT RING
|
|
| -51. |
3032623
|
|
SHIM-LINER(0.005"T)
|
|
| -52. |
3034663
|
[1] |
SHIM-LINER(0.008"T)
|
|
| N. |
@
|
[1] |
NOT SUPPLIED PARTS
|
|
