纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR ASN YT06-18001 (01-062[05]) - CAB INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
916 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONCab Glass Install YT02C01705F1 |
| 2. | LQ02C01301S001 | [1] | GLASS | SM |
| 3. | YT02C01705S002 | [1] | GLASS | KOB |
| 4. | LQ02C01301S003 | [1] | GLASS | SM |
| 5. | YT02C01705S004 | [1] | GLASS | KOB |
| 6. | LQ02C01301S005 | [1] | GASKET | SMStrip, Weather |
| 7. | LQ02C01301S006 | [2] | GASKET | SM |
| 8. | LQ02C01301S007 | [2] | PLUG | SMStopper |
| 9. | LQ02C01301S008 | [4] | SPACER | SM |
| 10. | LQ02C01301S009 | [6] | SPACER | SM |
| 11. | LQ02C01301S010 | [12] | SPACER | SM |
