现代零件查询R500LC-7 FLYWHEEL HOUSING(#0632-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
816 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
127316
|
[14] |
WASHER-PLAIN
|
|
| 2. |
182459
|
[1] |
GASKET-W/HEADER CVR
|
|
| 3. |
3008469
|
[1] |
PLUG-PIPE
|
|
| 4. |
3013786
|
[1] |
PLUG-PIPE
|
|
| 5. |
3018006
|
[2] |
SCREW-HEX HD CAP
|
|
| 6. |
3022148
|
[12] |
SCREW-HEX HD CAP
|
|
| 7. |
3025802
|
[2] |
SCREW-HEX HD CAP
|
|
| 8. |
3026134
|
[1] |
GASKET-COVER PLATE
|
|
| 9. |
3026135
|
[1] |
COVER-ACCESS HOLE
|
|
| 10. |
3063779
|
[3] |
PLUG-THREADED
|
|
| 11. |
3161671
|
[1] |
PLATE-COVER
|
|
| 12. |
3335044
|
[4] |
SCREW-HEX HD CAP
|
|
| . |
3417501
|
[1] |
HOUSING-FLYWHEEL
|
|
| N13. |
3417500
|
[1] |
HOUSING-FLYWHEEL
|
|
| 14. |
3819822
|
[1] |
SLEEVE
|
|
| . |
3255926
|
[1] |
HOUSING-FLYWHEEL
|
|
| 16. |
4083121
|
[12] |
SCREW-HEX FLANGE
|
|
| N17. |
4923644
|
[1] |
SEAL-OIL
|
|
| -1. |
4089542
|
[1] |
KIT-REAR SEAL CRANK
|
|
| N. |
4923644
|
[1] |
SEAL-OIL
|
|
| -11. |
4083121
|
[12] |
SCREW-HEX FLANGE
|
|
| N. |
@
|
[AR] |
NOT SUPPLIED PARTS
|
|
