纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR ASN YT06-18001 (01-088[01]) - HARNESS ASSEMBLY, UPPER (FLOOR) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
397 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF13E00042F1 | [1] | Upp., Floor | |
| 1. | LF13E00040F1 | [1] | Upp. | |
| 2. | LF13E01057P1 | [1] | WIRE HARNESS | KOB, Serial Range: YT06-18272-YT06-18351 Superseded by part number: LF13E01057P3 |
| 2. | LF13E01057P2 | [1] | WIRE HARNESS | KOB, Serial Range: YT06-18352-YT06-18441 Superseded by part number: LF13E01057P3 |
| 2. | LF13E01057P3 | [1] | WIRE HARNESS | KOB, Start Serial: YT06-18442 |
| 4. | PY01P01043D8 | [2] | CABLE TIE,102mm L | KOB |
| 3. | YN13E01375P1 | [20] | CLIP,M8 x 8.20mm Shank | KOB, Serial Range: YT06-18272-YT06-18316 |
| 5. | PY01P01043D3 | [20] | CABLE TIE,188mm L | KOB, Serial Range: YT06-18272-YT06-18316 |
